GXV3370 User Guide
Version 1.0.0.16
Back View
Figure 3: GXV3370 Back View
Table 5: GXV3370 Back View
Item
Name
Description
1
Camera Adjusting Wheel
Scroll up/down to adjust the camera angle.
2
Phone Stand (built-in)
Adjust the phone stand angle to place the phone on the desk.
3
Handset Port
RJ9 handset connector port.
4
Headset Port
RJ9 headset connector port (supporting EHS with
Plantronics headset).
5
LAN Port
10/100/1000Mbps RJ-45 port connecting to Ethernet.
PoE/PoE+ is supported.
6
PC Port
10/100/1000Mbps RJ-45 port connecting to PC.
7
Power Jack
12V DC Power connector port.
8
Side Connectors Cover
Open the cover for USB port, SD card slot, 3.5mm headset
port and mini HDMI port.
1
2
7
3
.
4
5
6
7
