Grandstream Networks UCM6510 Basic Configuration Guide

UCM6510 Basic Configuration Guide Page 23 of 29
 Click on to configure detailed parameters for the VoIP SIP trunk
 Click on to configure Direct Outward Dialing (DOD) for the SIP Trunk
 Click on to start LDAP Sync
 Click on to delete the VoIP trunk
There are 4 different types of VoIP trunks that can be configured:
 Peer SIP Trunk
 Register SIP Trunk
 Peer IAX Trunk
 Register IAX Trunk.
This tutorial will demonstrate how to configure a SIP Registered Trunk.
SET UP VOIP TRUNK
1. Click on “Create New SIP Trunk”.
2. Click the dropdown box for Type and select “Register SIP Trunk”.
3. Enter a name for “Provider Name” e.g., GSTrunk.
4. Configure the IP address or URL of the VoIP providers server as the “Host Name” e.g.,
sip.grandstream.com.
5. Input the username to authenticate with the VoIP provider as the “Username” e.g, 6266389172.
6. Enter password for username to authenticate with VoIP provider server.
7. Enter the AuthID. This is the SIP service subscriber’s ID used for authentication. If not configured, the
CallerID will be used for authentication.
8. Enter an outbound proxy if the provider requires one.
9. Click “Save” and then “Apply Changes” at the top.
