16
Cabling and Connections
Mainframe Connections
I IIP Input/Output
QSFP
A1 and B1 -
Primary
Inputs and
Outputs
A2 and B2 -
Secondary
Inputs and
Outputs
Inputs A1 and B1 - 1x 50GbE each Primary QSFP
connection. A1 is on the upper 'A' card, and B1 is on the
lower 'B' card.
Inputs - 18x on each Primary 50GbE input = 36x Inputs
Total
SMPTE 2022-6 or VSF TR-03 (SMPTE 2110) SD/HD/1080p
inputs across two 50GbE links. Each 50GbE link transports
9x SMPTE 2022-6 or VSF TR-03 (SMPTE 2110) SD/HD/1080p
inputs.
Outputs A1 and B1- 6x on each 50GbE output = 12x
Outputs Total
SMPTE 2022-6 or VSF TR-03 (SMPTE 2110) SD/HD/1080p
outputs across two 50GbE links. Each 50GbE link transports
3x SMPTE 2022-6 or VSF TR-03 (SMPTE 2110) SD/HD/1080p
outputs.
Inputs A2 and B2 - 1x 50GbE each Secondary QSFP
connection. A2 is on the upper 'A' card, and B2 is on the
lower 'B' card.
Inputs - 18x on each Secondary 50GbE QSFP
SMPTE 2022-6 or VSF TR-03 (SMPTE 2110) SD/HD/1080p
inputs across two 50GbE links. Each 50GbE link transports
9 x SMPTE 2022-6 or VSF TR-03 (SMPTE 2110)
SD/HD/1080p inputs.
Outputs A2 and B2 - 6 x on each secondary QSFP -
SMPTE 2022-6 or VSF TR-03 (SMPTE 2110) SD/HD/1080p
outputs across two 50GbE links. Each 50GbE link transports
3 x SMPTE 2022-6 or VSF TR-03 (SMPTE 2110)
SD/HD/1080p outputs.
Note: A2 and B2 Secondary are for redundancy..
Kula IP Mainframe Connectors
Connectors Description Connector Information
Note: Inputs and Outputs will vary, depending on the Kula system
purchased.
