Specifications
Kula Mainframe
Kula 12G-SDI Mainframe Connections
Kula 12G-SDI Mainframe Bi-Directional Inputs/Outputs
Bi-directional
Inputs and
Outputs
2x Tri standard, SD-SDI/HD-SDI/3Gbps-SDI BNC Inputs
or
2x 1080p SDI/HD-SDI/SD-SDI (270Mbps / 1.485Gbps / 2.97Gbps) BNC
Outputs
Kula 12G-SDI Mainframe Inputs Formats & Levels
SDI Input
Format
Tri Standard 1080p 2.97Gbps/HD 1.485 Gbits/second and SD
270Mbits/second serial digital interface as per ANSI/SMPTE-259/292M and
12G-SDI (SMPTE 2082) Single Link
Analogue HD
Reference
±300mV tri-level sync 6dB
Analogue SD
Reference
300mV sync with optional 300mV pk-pk burst 6dB
Impedance 75 ohms (except reference input).
Kula 12G-SDI Mainframe Inputs
Inputs 40 x HD/SD/1080p (270Mbps / 1.485Gbps / 2.97Gbps) Inputs.
Serial digital interface As REC601/ SMPTE/292M / SMPTE424M via BNC
connectors.

Including 10 x 12G-SDI (SMPTE 2082) single link BNC connectors
Kula 12G-SDI Mainframe Output Formats & Levels
SDI Output
Format
Tri Standard 3Gbps-SDI/HD-SDI/SD-SDI 1080p (270Mbps / 1.485Gbps /
2.97Gbps)and 12G-SDI (SMPTE 2082) Single Link
Analogue
Sync
±300mV tri-level HD sync or 300mV SD sync according to system standard
Output
Impedance
75 ohms
Kula 12G-SDI Mainframe Outputs
Outputs 12 x HD/SD/1080p (270Mbps / 1.485Gbps / 2.97Gbps) Outputs
Serial digital interface As REC601/ SMPTE/292M / SMPTE424M via BNC
connectors.

Including 3 x 12G-SDI (SMPTE 2082) single link BNC connectors
Note: All other connectors on the mainframe are the same as the standard
Kula SDI mainframe
