Specifications
Kula Control Surface Specifications
Kula KPX and KPP Control Surface
Connector Description
Power Supply 2x 4 pin PSU Connectors - Kycon KPPX 4 Pin or Compatible
12V DC 8.33A
Inrush Current 7.8A
USB 2x USB 2 Connectors
Video Output Digital Video Monitor Output (MON) connector. To connect to a touch screen
GUI
Network 10/100/1000 base T, Auto - MDX/MDXI on RJ45 connectors
Connections to
the K1X and
K1P Control
Surface
6x RJ45 connectors (in total) for Comms and +12V 0.42A power supply
Connection to the K1X and K1P control surface.
NOT Ethernet, connections must be direct to the control surface. Do Not use
network switches or hubs.
CAT5 or above cables - crossover cables are Not suitable.
Kula K1X and K1P Control Surface
Power and
Comms
Description
Connections
to the KPX and
KPP

Control
Surface
2x RJ45 connectors for Comms and +12V 0.42A power supply in from the
KPP control surface.
NOT Ethernet, connections must be direct to the control surface. Do Not
use network switches or hubs.
CAT5 or above cables - crossover cables are Not suitable.
Kula K5P Control Surface
Connector Description
Power Supply 2x 4 pin PSU Connectors - Kycon KPPX 4 Pin or Compatible
12V DC 8.33A
Inrush Current 8.7A
USB 2x USB 2 Connectors
Video Output Digital Video Monitor Output (MON) connector. To connect to a touch screen
GUI
Network 10/100/1000 base T, Auto - MDX/MDXI on RJ45 connectors
Comms 
Connectors
2x RJ45 connectors for Comms and +12V 0.42A power supply
NOT Ethernet, connections. Do Not use network switches or hubs.
CAT5 or above cables - crossover cables are Not suitable.
