40
TRACTOR ASSEMBLY
Item Order Description
No. No.
Item Order Description
No. No.
Item not pictured:
605363 Decal Set - 124 Mower
01-12058
Rev. 06-13
1 645376 Frame
2 100153 Engine
3 100919 Air Filter - Cyclonic
4 100803 Oil Filter
5 101197 Muffl er
101043 Gasket - Muffl er
6 243016 Tap Screw
7 424319 Hose Assembly - Drain
8 365515 Plug
9 254431 Speed Nut
10 729734 Shield – Rear Guard
11 142250 Mechanical Choke
12 603854 Throttle Assembly
323643 Cable Assembly
722009 Throttle Lever Stop
722736 Throttle Stop – Heavy Duty
13 422150 Handle Grip
14 723062 Mount - Battery
15 420610 Hold Down Stra
16 424250 Grommet
17 605791 Fuel Tank Assembly
(includes items 18-21)
18 100212 Cap – Fuel Sealed Tether
19 363925 Fuel Tube
20 101875 Bushing – Fuel Tube
21 100216 Valve – Fuel Tank
22 730451 Rod – Fuel Tank Mount
23 254450 Nut
24 253043 Whiz Nut
25 821760 Fuel Hose
26 821768 Fuel Hose
27 366560 Fuel Filter
28 280260 Hose Clamp – Spring
29 751043 Shield - Heat
30 644410 Bracket - Console
31 645102 Console
32 253176 Whiz Bolt - Truss
33 253025 Whiz Nut
34 253177 Whiz Bolt - Truss
35 483924 Wheel & Tire
483420 Wheel Without Tire
482474 Tire
36 248565 Lug Bolt
37 645238 Fender – Rt.
38 645239 Fender – Lt.
39 822631 Trim – Fender Edge
40 422079 Hole Plug – Work Lamp
41 150225 Cup Holder
42 259030 Cap Screw - Hex
43 254436 Nut - Nylon
44 253173 Whiz Bolt - Hex
45 782898 Strap - Tension
46 253067 Flange Nut - Spirol Loc
243565 Bolt
