Grasshopper 124/52 User Manual

46
Item Order Description
No. No.
SEAT ASSEMBLY & OPS TUBE
Item Order Description
No. No.
12060
1 321518 Seat Cushion
2 321519 Back Cushion
3 321523 Arm Rest Cushion
4 723433 Seat Side – Raised Rt.
5 723434 Seat Side – Raised Lt.
6 822630 Trim – Seat Edge
7 643898 Seat Pan
8 722884 Seat Reinforcement - Raised
163295 Decal - Grasshopper Emblem
9 183871 Seat Switch - Twist
10 644401 Bracket – Seat Pivot Rt.
11 644402 Bracket – Seat Pivot Lt.
12 422565 Sleeve Bearing w/Flange
13 253175 Bolt - Hex
14 724930 Latch - Switch
15 724929 Mount Bracket – Seat Latch
16 730229 Pivot Pin – Seat Latch
17 284408 Spring Torsion
18 260606 Ring Cotter
19 253176 Whiz Bolt - Truss
20 253025 Whiz Nut
21 324200 Seat Belt
22 243551 Bolt
23 257063 Nylon Washer
24 257062 Washer - SAE
25 253470 Nut - Nylon Insert
26 253191 Whiz Bolt
27 253193 Whiz Bolt
28 729736 Cross Member – Seat
29 283516 Seat Spring – Compression
30 422127 Cap – Seat Spring
31 253203 Whiz Bolt
32 253043 Whiz Nut
33 751042 Shield – Fan
34 253173 Whiz Bolt - Hex
35 729734 Shield – Rear Guard
36 324111 OPS Tube
165092 Decal - Warning OPS
37 243600 Bolt
253930 Lock Nut
