Grasshopper 124/52 User Manual

52
DECK CARRIER LINKAGE
Item Order Description
No. No.
Item Order Description
No. No.
12061
1 645316 Footrest
2 424074 Vibration Isolator
3 253035 Whiz Nut
4 776214 Radius Arm
5 243805 Bolt
6 253970 Lock Nut
7 645274 Guide – Latch Tube
8 645845 Tube – Height Adjust
9 730434 Deck Pin – Height Adjust
10 253215 Flange Bolt
11 253043 Whiz Nut - Lg Flange
12 423643 Lift Bearing Block
13 774064 Plate – Lift Bearing
14 645650 Pivot – Front Carrier
15 604762 Spring & Plug Nut Assembly
16 243399 Bolt - Full Thread
17 902280 Spacer
18 881154 Shaft – Spring Mount
19 644644 Pivot Carrier
20 243360 Bolt
21 902412 Spacer
22 603741 Rocker Assembly Rt.
121764 Oilite Bearing
23 603728 Rocker Assembly Lt.
121764 Oilite Bearing
24 263529 Retainer - External
25 732586 Adjusting Strap
26 243205 Bolt
27 820331 Chain – 5 Links
28 243458 Flange Bolt
29 253058 Whiz Nut
30 732811 Strap – Carrier Linkage
31 260608 Ring Cotter
32 123522 Bearing Cup
33 122522 Bearing – Tapered
34 257320 Washer – Spring
35 254505 Jam Nut - Nylon Top lock
36 481432 Dust Cap
37 125855 Seal
38 282615 Spacer
39 645221 Fork
40 247725 Carriage Bolt
41 257051 Washer - SAE
42 603975 Wheel & Tire Assembly
w/Bearings & Spacer
43 902429 Bearing Spacer
44 120048 Wheel Bearing
45 902422 Spacer
46 729685 Mount – Height Adjust
47 821516 Washer – Nylon
48 243560 Bolt
49 253470 Nut - Nylon Insert
50 775147 Latch – Deck
51 253192 Whiz Bolt
52 253450 Nut - Nylon Insert
53 243340 Bolt
54 253460 Nut - Nylon Insert
55 423696 Spacer – Height Adjustment
