Grasshopper 124/52 User Manual

48
Item Order Description
No. No.
Item Order Description
No. No.
1 321570 Seat Assembly - Molded
2 183870 Switch - Seat
3 243026 Bolt - Washer Head Tap
4 643898 Seat Pan
5 253193 Whiz Bolt
6 422565 Sleeve Bearing with Flange
7 724929 Mount Bracket – Seat Latch
8 724930 Latch – Seat
9 730229 Pivot Pin – Seat Latch
10 284408 Spring - Torsion
11 260606 Ring Cotter
12 253176 Whiz Bolt - Truss
13 253025 Whiz Nut
14 324200 Seat Belt
15 243551 Bolt
16 257063 Washer
17 257062 Washer - SAE
18 253470 Nut - Nylon Insert
19 770160 Decal Plate - Seat
163295 Decal – Grasshopper Emblem
20 246975 Push Stud - Plastic
12065
OPTIONAL MOLDED SEAT ASSEMBLY
