DECK ASSEMBLY - MODEL M252
Item Order Description
No. No.
Item Order Description
No. No.
12063
1 645189 Deck
2 824473 Idler Arm Assembly
(includes items 3-5)
3 121756 Bearing - Oilite
4 257319 Washer - Spring
5 121651 Bearing Pedestal
6 257160 Washer
7 393250 Idler 6.0
8 257062 Washer SAE
9 243575 Bolt
10 423670 Stabilizer Cap
11 253067 Nut Flange Spiral Lock
12 784057 Tube - Guide
13 243038 Bolt
14 253025 Whiz Nut
15 422520 Nylon Bearing
16 283852 Spring - Extension
17 257040 Washer
18 253043 Whiz Nut
19 393225 Idler 4.75
20 902313 Spacer
21 730391 “J” Bolt – Idler Adjustment
22 254450 Nut
23 776214 Radius Arm
24 243800 Bolt
25 253970 Lock Nut
26 415902 Sheave
27 603725 Center Roller Assembly
28 644512 Lock Pin - Roller
29 253192 Whiz Bolt
30 253035 Whiz Nut
31 754203 Roller Mount – Formed Rt.
32 776231 Spacer – Roller Mount
33 426122 Roller
34 902284 Spacer – Roller Mount
35 243365 Bolt
36 645579 Mount – Anti-Scalp Roller Lt.
37 484230 Wheel – Anti-Scalp
38 942137 Bearing Tube
39 247310 Carriage Bolt
40 247130 Carriage Bolt
41 257059 Cupped Washer
42 243590 Bolt
43 424163 Deck Flap
44 774219 Strap - Defl ector
45 253179 Bolt - Phil. Truss
46 382111 Belt
47 643632 Pivot Mount
48 604317 Discharge Shield Assembly
(includes items 49-53)
49 422042 Discharge Shield
50 644570 Mount – Discharge Shield
51 284406 Spring - Torsion
52 780650 Pin
53 260608 Ring Cotter
54 252821 Stud – 3 Prong Head
55 820331 Lift Chain – 5 Links
56 243458 Bolt
57 253058 Whiz Nut
58 254431 Speed Nut
59 254448 Speed Nut
60 320239 Blade 18” High Lift Notched
320240 Blade 18” Hi-Low Mulching
320236 Blade 18” Medium Lift
320238 Blade 18” Contour
61 751046 Shield – Belt Rt.
62 751047 Shield – Belt Lt.
63 253175 Whiz Bolt
64 724588 Auxiliary Front Shroud
65 253176 Whiz Bolt - Truss
66 644608 Mulch Plate Rt. (Optional)
67 644609 Mulch Plate Lt. (Optional)
68 644058 End Cap (Optional)
To Next Page
