Grasshopper 223 - Drive Assembly

40
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
DRIVE ASSEMBLY
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
02-02017E
Rev. 05-08
1 644634 Pump Plate - 200
2 415888 Sheave
3 415882 Sheave
4 824573 Idler Arm (includes items 5, 38 & 50)
5 121651 Bearing - Pedestal
6 243365 Bolt .375-16 x 3
7 257040 Washer .375
8 253043 Whiz Nut .375-16
9 257412 Lock Washer .375
10 253890 Lock Nut .375-16
11 393195 Idler Pulley 3.46
12 257062 Washer .5 SAE
13 243601 Bolt .5-13 x 3 Full Thread
14 257432 Lock Washer .5
15 254470 Nut .5-13
16 422558 Nylon Bearing
17 253930 Lock Nut .5-13
18 243580 Bolt .5-13 x 2
19 774020 Washer .406
20 270821 Hex Flange Bolt M6 x 1 x 12mm
21 257019 Flat Washer .25 Hard
22 382034 Belt
23 388740 Clutch
24 281582 Square Key .25 x .875
25 755125 Anti-Rotation Bracket
26 422088 Cover - Clutch Bracket
27 283848 Spring - Extension
28 730391 “J” Bolt - Idler Adjustment
29 254450 Nut .375-16
30 243340 Bolt .375-16 x 1.5
31 283820 Spring - Extension w/Swivel
32 243470 Bolt .437-20 x 2.5
33 824486 Idler Arm - Mule Drive
(includes items 5 & 38)
34 393376 Idler Pulley 4.0 w/Hub
35 243355 Bolt .375-16 x 2.5
36 281301 Rubber Draw Latch
37 393390 Idler Pulley 6.0
38 121756 Bearing - Oilite
39 883804 Spacer .312
40 382085 Belt (52" & 61" Deck)
382095 Belt (72" Deck)
41 732520 Spring Bracket - Idler Arm
42 243445 Bolt .437-14 x 1
43 257422 Lock Washer .437
44 604755 Shield Assembly
(includes items 45 &47)
45 422090 Isolator - Rear Belt Shield
46 243330 Bolt .375-16 x 1
47 424015 Rubber Bumper
48 243575 Bolt .5-13 x 1.75
49 253066 Whiz Nut .5-13
50 257319 Washer - Spring
