137
»Control adjust« (page 58)
FREE
FREE
… in order to conclude the programming procedure.
This is where you assign an On / Off switch instead
of the slider. This can be any switch you like (e.g. “3”),
assigned to the control channel you have selected –
in these examples “transmitter control 7” to channel
“9”. Enter the desired SYMmetrical or ASYmmetrical
time delay in the “–Time+” column; this is the period
in which the function is to complete its course.
Note:
When assigning the switch to this function, please
bear in mind that a single switch can be used to trig-
ger several functions. For example, the same switch
could be used to operate a retract system connected
to output 6, and – as shown in this example – operate
the time-delayed wheel doors connected to output 9,
and / or the delayed-action searchlight, etc..
Programming examples – Fixed-wing models
