Description of program expansions and operating notes
Description of program expansions and operating notes
Page
Page
Undelayed channel The delay when a new fl ight phase is selected can be switched off for individual channels, separately for each
ight phase. Examples: motor OFF with electric models, activating and disabling heading lock with gyro systems.
81
Timers
Timers
Timers “Model time”: Reset with brief press on the rotary control when the CLR eld is active (timer switchable).
“Battery time”: Automatic reset when battery is recharged; can also be reset by pressing CLR.
“Stopwatch”: The stopwatch is switched on and off by means of the switch assigned on the right of the screen.
Pressing CLEAR in the basic display resets the stopwatch to zero, but only if the timing process
has already been halted.
“Flight timer“: The fl ight timer is switched on via the switch assigned on the right. Operate the same switch and
press ESC at the basic display to stop the timer; CLEAR resets it to zero.
“Timer” column: Preset 0:00 means count-up timer; time preset via rotary control (maximum 180 min 59 sec) ge-
nerates count-down timer (fl ashing colon (:) in the basic display).
“Alarm” column: Time and sequence of the warning sounds until the alarm timer passes through zero (max. 90
sec.).
82
Mixers
Mixers
Wing mixers Number of available mixers varies according to »Model type« menu: aileron differential, fl ap differential, aileron 2
4 rudder, aileron 2 7 fl aps, brake 3 elevator, brake 6 fl ap, brake 5 aileron, elevator 3 6 fl aps, ele-
vator 3 5 aileron, fl aps 6 3 elevator, fl aps 6 5 aileron and differential reduction. All mixers: the mixer ra-
tio can be varied within the range -150% and +150%, separately for each fl ight phase. All wing mixers with fl ap or
elevator inputs can also be programmed separately for each side of neutral. The neutral point (offset) of the “aile-
ron, elevator, fl ap NN” mixers is the zero point of the transmitter control; the neutral point (offset) of the “brake
NN” mixer can be programmed in the »Model type« menu.
All mixers are switchable.
84
Helicopter mixer Programming separately for each fl ight phase:
a) Non-linear fi ve-point curves for: collective pitch, channel 1 throttle and channel 1 tail rotor; adjus-
ted as in »Channel 1 curve« menu, and
b) linear mixer ratios (0 ... 100%) for the following mixers: tail rotor throttle, roll throttle, roll tail ro-
tor, pitch-axis throttle and pitch-axis tail rotor.
Gyro suppression: Suppression of gyro effect through tail rotor defl ection (0 ... 199%), variable separate-
ly for each fl ight phase, dependent on tail rotor stick position. Programmed values abo-
ve 100% produce full suppression before full tail rotor defl ection. Also available in the
auto-rotation phase.
Swashplate rotation: (Virtual) rotation of the swashplate in either direction (-90° ... +90°).
The following mixers are available in the auto-rotation phase:
90
