Basic operation of the “3-D rotary control”
Screen contrast adjustment, multi-function list, menu settings
Rotary control
Rotary control functions
The basic method of using the rotary control has al-
ready been described on page 18. Here we show an
example of using the rotary control in a practical ap-
plication, to provide a better idea of its functionality.
First switch the transmitter on. Set the transmission
channel (see page 22), and you will move to the basic
screen display.
• Adjusting screen contrast
Press and ro-
tate:
• Select multi-function list
Rotate: (select
menu)
• Menu settings
Press the rotary control (or ENTER)
briefl y to move to a menu.
Now select a line:
Press and ro-
tate:
Call up an input fi eld:
Brief press:
Change a value:
Rotate:
Confi rm input and quit:
Brief press:
Call up next parameter fi eld:
Rotate:
Model name
#01 0:00h C73
H-J Sandbrunner
10.8V
0:00h
0 0 0 0
St watch
Flighttm
0 00
0 00
:
:
Model name
#01 0:00h C73
H-J Sandbrunner
10.8V
0:00h
0 0 0 0
St watch
Flighttm
0 00
0 00
:
:
ENTER ESC
Model select Copy / Erase
Suppress codes Base setup model
Model type Servo adjustment
Control adjust Dual Rate / Expo
Switch display Timers
Wing mixers Basic Settings
B A S I C S E T T I N G S , M O D E L
M o d e l n a m e < >
S t i c k m o d e 2
M o d u l a t i o n
P P M 1 8
T r i m s t e p s 4 4 4 4
C H 1 A I L E E L E V R U D D
t
s
B A S I C S E T T I N G S , M O D E L
M o d e l n a m e < >
S t i c k m o d e 2
M o d u l a t i o n
P P M 1 8
T r i m s t e p s
4 4 4 4
C H 1 A I L E E L E V R U D D
t
s
B A S I C S E T T I N G S , M O D E L
M o d e l n a m e < >
S t i c k m o d e 2
M o d u l a t i o n
P P M 1 8
T r i m s t e p s
1 0 4 4 4
C H 1 A I L E E L E V R U D D
t
s
B A S I C S E T T I N G S , M O D E L
M o d e l n a m e < >
S t i c k m o d e 2
M o d u l a t i o n
P P M 1 8
T r i m s t e p s 1 0 4 4 4
C H 1 A I L E E L E V R U D D
t
s
"!3)#3%44).'3-/$%,
-ODELNAME
3TICKMODE
-ODULATION 00-
4RIMSTEPS
#(
!),%%,%625$$
Turn the rotary control to change the rest of the pa-
rameter fi elds, in this case CH1, AILE, ELEV, RUDD
(in each case the element which can be changed ap-
pears in inverse video, i.e. with a black background),
and press it to move from the selected parameter
fi eld to the change fi eld, etc.
Finally press ESC to return to the multi-function list.
