Switches
• • Switch display When an external switch or control switch is operated, this displays the associated switch number and switch po-
sition.
72
• • Control switch Assign the control switches 1 ... 4 to the transmitter controls 1 ... 10. Pressing STO (press the rotary control) in co-
lumn 3 stores the current control position as the switching point. Reverse the switching direction in column 4, and
assign a switch to activate (and disable) a control switch in column 5. Column 6 displays the switch status.
72
• Auxiliary switch Auto-rotation: a switch assigned to this function activates the Auto-rotation fl ight phase. It has priority
over all other fl ight phase switches and the Auto-rotation Ch1 position switch.
Auto-rotation Ch1 Pos.: Alternative auto-rotation switch: defi nes a switching point on the Ch1 stick, can be activa-
ted using STO. External switch required! For more details see »Phase setting« menu.
75
Flight phases
• Phase setting Name: In the »Phase assignment« menu names from a list are assigned to up to four phases (normal,
launch, ...), according to the position of the fl ight phase switches. The names are shown in the
basic display and in all programs which are fl ight phase-specifi c.
Transition time: It is advisable to set a transition time at this point (0 ... 9.9 sec) to avoid abrupt changes between
different fl ight phases; this provides a “soft” transition.
Meaning of symbols in right-hand column:
Indicates the phase assigned to each switch position. Phase 1 by default if no other switches are
assigned, or if all phase switches are at the base position.
+
A switch position is provided for this phase in the »Phase setting« menu.
–
The phase is not in use.
78
• Phase setting In contrast to »Phase setting« for fi xed-wing models, the name of the auto-rotation phase cannot be changed.
This fl ight phase can be activated if a switch is defi ned in the »Auxiliary switch« menu. For more information see
the »Phase assignment« menu.
Transition time: It is advisable to set a transition time at this point (0 ... 9.9 sec) to avoid abrupt changes between
different fl ight phases; this provides a “soft” transition. If auto-rotation is selected, the switch
takes place without any delay; any set delay only takes effect when you quit auto-rotation.
Meaning of symbols in right-hand column: see »Phase setting« menu for fi xed-wing model
79
• • Phase assignment Each of the four (fi xed-wing model) or three (model helicopter) available fl ight phases can be assigned to any
combination of up to four switches; the phases can be assigned names in the »Phase setting« menu. In the
basic setting all switches always generate “Phase 1”; the same applies to non-assigned switch combinations.
Priority of the switch assigned under “A”:
The fl ight phase assigned to this switch has precedence over the fl ight phase switch positions “B”, “C” and “D”.
80
Brief programming instructions
