31
Switch assignment
Meaning of the fi xed switch “FX”
The two FX switches which appear in the above list
are known as “fi xed switches”, which switch a function
on permanently …
FXI
or off permanently.
FX
Possible applications are included in example 2 on
page 107.
The two switches can also be used for the transmitter
control inputs in the »Control adjust« menu:
The closed fi xed switch “FXI” generates a fi xed travel
of +100%, the open fi xed switch “FX ” a value of
-100%. Other values can be obtained by changing the
servo travel.
Note:
All switches can also be assigned to multiple
functions. Please take care to avoid assigning se-
veral functions to one switch accidentally! We re-
commend that you take careful note of the switch
functions you have assigned.
5. To erase the control switch:
Press the CLEAR button at the following display:
The control switch must now be assigned to
the control (transmitter control) you wish to
use: 1 ... max. 10. You also have to defi ne the
switching point between ON and OFF or vice ver-
sa. Both points are carried out in the »Control
switch« menu; see page 72.
Move desired switch
to ON position
(ext. switch: ENTER)
