Jaguar II User Manual
Installation and Operation of Sign Cutting Plotter 2-4
Step 7
Place two roll holders into the holes in the roll holder support (Figure 2-7)
Step 8
Lastly, the complete picture will be shown like below. (see Figure 2-8)
Roll holder support
Roll holders
Figure
Figure 2-8
