Grizzly G0454Z User Manual

-52-
Model G0453Z/G0454Z (Mfg. 1/09+)
G0453Z Stand Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P0453Z501 STAND ASSEMBLY 531 P0453Z531 SHAFT 12MM
502 P0453Z502 BACK CABINET COVER 532 P0453Z532 HEX BOLT M8-1.25 X 50
503 P0453Z503 FRONT CABINET COVER 533 P0453Z533 FLAT WASHER 8MM
504 P0453Z504 PHLP HD SCR M6-1 X 20 534 P0453Z534 HEX NUT M8-1.25
505 P0453Z505 MOTOR MOUNT PLATE 535 P0453Z535 HEX NUT M10-1.5
506 P0453Z506 SET SCREW M6-1 X 12 536 P0453Z536 FLAT WASHER 10MM
507 P0453Z507 PLATE CONNECTING ROD 537 P0453Z537 HEX BOLT M8-1.25 X 100
507-1 P0453Z507-1 BUSHING 538 P0453Z538 FLAT WASHER 8MM
508 P0453Z508 SET SCREW M8-1.25 X 12 539 P0453Z539 TROLLEY WHEEL BOLT
509 P0453Z509 PLATE CONNECTING ROD 540 P0453Z540 INT RETAINING RING 35MM
510 P0453Z510 HEX BOLT M10-1.5 X 70 541 P0453Z541 BALL BEARING 6202-2RS
511 P0453Z511 FLAT WASHER 10MM 542 P0453Z542 TROLLEY WHEEL
512 P0453Z512 HEX NUT M10-1.5 543 P0453Z543 TROLLEY WHEEL SLEEVE
513 P0453Z513 LOCK COLLAR 544 P0453Z544 TROLLEY UNIVERSAL KIT
514 P0453Z514 SET SCREW M6-1 X 8 545 P0453Z545 FLAT WASHER 10MM
515 P0453Z515 ADJUST BOLT 546 P0453Z546 HEX NUT M12-1.75
516 P0453Z516 HEX NUT M12-1.75 547 P0453Z547 HEX BOLT M10-1.5 X 55
517 P0453Z517 FLAT WASHER 12MM 548 P0453Z548 BRACKET
518V2 P0453Z518V2 MOTOR 3HP 240V 1-PH V2.05.08 549 P0453Z549 PEDAL
518-1 P0453Z518-1 MOTOR FAN COVER 549A P0453Z549A PEDAL ASSEMBLY
518-2 P0453Z518-2 MOTOR FAN 550 P0453Z550 EXT RETAINING RING 9MM
518-3V2 P0453Z518-3V2 S CAPACITOR 250M 250V 1-3/4 X 3-1/2 551V2 P0453Z551V2 MAGNETIC SWITCH ASSY V2.01.11
518-4V2 P0453Z518-4V2 R CAPACITOR 40M 450V 1-3/8 X 2-3/8 551-1 P0453Z551-1 MAG SWITCH COVER ASSEMBLY
518-5V2 P0453Z518-5V2 JUNCTION BOX V2.05.08 551-2 P0453Z551-2 CONTACTOR NHD C-09D 230V
518-6 P0453Z518-6 BALL BEARING 6205ZZ 551-3 P0453Z551-3 OL RELAY NHD NTH-17 14-17
518-7 P0453Z518-7 BALL BEARING 6203ZZ 551-5 P0453Z551-5 SWITCH COVER SCREW WHITE
518-8 P0453Z518-8 CENTRIFUGAL SWITCH 16MM 3450 552 P0453Z552 FLAT HD SCR M5-.8 X 20
518-9 P0453Z518-9 CONTACT PLATE 16MM 553 P0453Z553 FLAT WASHER 5MM
519 P0453Z519 KEY 5 X 5 X 30 554 P0453Z554 HEX NUT M5-.8
520 P0453Z520 FLAT WASHER 8MM 555 P0453Z555 HEX BOLT M8-1.25 X 20
521 P0453Z521 HEX NUT M8-1.25 556 P0453Z556 SUPPORT ARM 22"
522 P0453Z522 HEX BOLT M8-1.25 X 45 557 P0453Z557 HEX BOLT M6-1 X 16
523 P0453Z523 BALL STRAIN RELIEF 558 P0453Z558 HEX BOLT M6-1 X 16
524 P0453Z524 HEX NUT M8-1.25 559 P0453Z559 BALL STRAIN RELIEF
525 P0453Z525 FLAT WASHER 8MM 560 P0453Z560 CONTROL BOX
526 P0453Z526 SLEEVE 561 P0453Z561 CONTROL PANEL
527 P0453Z527 UNIVERSAL WHEEL 78MM DIA 562V2 P0453Z562V2 START BUTTON CLEAR V2.01.11
528 P0453Z528 HEX BOLT M8-1.25 X 65 563V2 P0453Z563V2 E-STOP BUTTON 3-ARROW V2.01.11
529 P0453Z529 RUBBER FOOT 564 P0453Z564 TAP SCREW #10 X 3/8
529-1 P0453Z529-1 HEX NUT 3/8-16 565 P0453Z565 PLASTIC GROMMET
530 P0453Z530 FLAT WASHER 12MM 566V2 P0453Z566V2 POWER CORD 12G 3W 72" 6-20P V2.08.12
