Grizzly G0454Z User Manual

-55-
Model G0453Z/G0454Z (Mfg. 1/09+)
G0454Z Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0454Z001 HANDWHEEL HANDLE 54 P0454Z054 KEY 8 X 8 X 36
2 P0454Z002 HEX NUT M12-1.75 55 P0454Z055 BALL BEARING 6206ZZ
3 P0454Z003 FLAT WASHER 12MM 56 P0454Z056 HEX BOLT M6-1 X 16
5 P0454Z005 HANDWHEEL 57 P0454Z057 FLAT WASHER 6MM
6 P0454Z006 HANDWHEEL COLLAR 58 P0454Z058 OUTFEED ROLLER SPROCKET
7 P0454Z007 INT RETAINING RING 32MM 59 P0454Z059 HANDWHEEL SCALE
8 P0454Z008 BALL BEARING 6201ZZ 60 P0454Z060 FLAT WASHER 6MM
9 P0454Z009 KEY 4 X 4 X 20 61 P0454Z061 PHLP HD SCR M6-1 X 12
10 P0454Z010 WORM GEAR 62 P0454Z062 CUT LIMITER POINTER
11 P0454Z011 WORM HOUSING 63 P0454Z063 FLAT WASHER 6MM
12 P0454Z012 CAP SCREW M6-1 X 60 64 P0454Z064 PHLP HD SCR M6-1 X 12
13 P0454Z013 RETURN ROLLER 65 P0454Z065 CUT LIMIT PLATE
14 P0454Z014 ROLLER STAND 66 P0454Z066 HEX BOLT M5-.8 X 12
15 P0454Z015 CAP SCREW M6-1 X 16 67 P0454Z067 HEAD CASTING
19 P0454Z019 DUST HOOD 68 P0454Z068 OUTFEED ROLLER
20 P0454Z020 FLANGE BOLT M6-1 X 12 69 P0454Z069 KEY 5 X 5 X 22
21 P0454Z021 UPPER COVER 70 P0454Z070 COMPRESSION SPRING
22 P0454Z022 FLANGE BOLT M6-1 X 12 71 P0454Z071 OILER SET SCREW
23 P0454Z023 TOP COVER GASKET 72 P0454Z072 FEED ROLLER BLOCK
24 P0454Z024 CHAIN DRIVE COVER 73 P0454Z073 ADJUSTMENT PLATE
26 P0454Z026 CAP SCREW M8-1.25 X 40 74 P0454Z074 HEX BOLT M8-1.25 X 20
27 P0454Z027 ROLL PIN 6 X 20 75 P0454Z075 SET SCREW M6-1 X 20
28 P0454Z028 REAR SAFETY HATCH 76 P0454Z076 HEX NUT M6-1
29 P0454Z029 FRONT SAFETY HATCH 77 P0454Z077 PRESSURE PLATE SHAFT
30 P0454Z030 FLANGE BOLT M6-1 X 10 78 P0454Z078 SET SCREW M6-1 X 16
31 P0454Z031 IDLER PULLEY/BRACKET ASSY 79 P0454Z079 CHIP BREAKER
32 P0454Z032 IDLER MOUNTING SHAFT 80 P0454Z080 SET SCREW M6-1 X 20
33 P0454Z033 IDLER BRACKET COLLAR 81 P0454Z081 HEX NUT M6-1
34 P0454Z034 EXTENSION SPRING 82 P0454Z082 CHIP BREAKER BRACKET
35 P0454Z035 HANGER 83 P0454Z083 LOCK ROD
36 P0454Z036 CAP SCREW M6-1 X 10 84 P0454Z084 FLAT WASHER 8MM
37 P0454Z037 CHIP DEFLECTOR PLATE 84-1 P0454Z084-1 HEX BOLT M8-1.25 X 12
38 P0454Z038 FLANGE BOLT M6-1 X 15 85 P0454Z085 HEX NUT M12-1.75
39 P0454Z039 FLAT WASHER 6MM 85-1 P0454Z085-1 FLAT WASHER 8MM
40 P0454Z040 HOLD DOWN PLATE 86 P0454Z086 PRESSURE BAR
41 P0454Z041 FLANGE BOLT M6-1 X 12 87 P0454Z087 HEX BOLT M8-1.25 X 20
42 P0454Z042 PLATE SPRING 88 P0454Z088 LOCK WASHER 8MM
43 P0454Z043 FLANGE BOLT M6-1 X 12 89 P0454Z089 E-CLIP 15MM
44 P0454Z044 ADJUSTING SHAFT 90 P0454Z090 ANTI-KICKBACK SHAFT COLLAR
45 P0454Z045 SET SCREW M6-1 X 12 91 P0454Z091 ANTI-KICKBACK FINGER
46 P0454Z046 SET SCREW M6-1 X 20 92 P0454Z092 ANTI-KICKBACK FINGER SHAFT
47 P0454Z047 HEX NUT M6-1 93 P0454Z093 SET SCREW M8-1.25 X 12
53 P0454Z053 SPIRAL CUTTERHEAD ASSY 20" 94 P0454Z094 HEX BOLT M6-1 X 16
53-1 P0454Z053-1 FLAT HD TORX T20 M6-1 X 15 95 P0454Z095 FLAT WASHER 6MM
53-2 P0454Z053-2 INDEXABLE INSERT 14 X 14 X 2 96 P0454Z096 INFEED ROLLER SPROCKET
