Grizzly G0454Z User Manual

-61-
Model G0453Z/G0454Z (Mfg. 1/09+)
G0454Z Stand Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P0454Z501 ENCLOSED STAND 531 P0454Z531 SHAFT 12MM
502 P0454Z502 REAR COVER 532 P0454Z532 HEX BOLT M8-1.25 X 50
503 P0454Z503 FLAT HD SCR M6-1 X 20 533 P0454Z533 FLAT WASHER 8MM
504 P0454Z504 MOTOR MOUNT PLATE 534 P0454Z534 HEX NUT M8-1.25
505 P0454Z505 SET SCREW M6-1 X 12 535 P0454Z535 HEX NUT M10-1.5
506 P0454Z506 PLATE CONNECTING ROD 536 P0454Z536 FLAT WASHER 10MM
507 P0454Z507 SET SCREW M8-1.25 X 12 537 P0454Z537 HEX BOLT M8-1.25 X 100
508 P0454Z508 PLATE CONNECTING ROD 538 P0454Z538 FLAT WASHER 8MM
509 P0454Z509 HEX BOLT M10-1.5 X 70 539 P0454Z539 TROLLEY WHEEL BOLT
510 P0454Z510 FLAT WASHER 10MM 540 P0454Z540 INT RETAINING RING 35MM
511 P0454Z511 HEX NUT M10-1.5 541 P0454Z541 BALL BEARING 6202-2RS
512 P0454Z512 CONNECTING ROD LOCK COLLAR 542 P0454Z542 TROLLEY WHEEL
513 P0454Z513 SET SCREW M6-1 X 8 543 P0454Z543 TROLLEY WHEEL SLEEVE
514 P0454Z514 ADJUST BOLT 544 P0454Z544 TROLLEY UNIVERSAL KIT
515 P0454Z515 HEX NUT M12-1.75 545 P0454Z545 FLAT WASHER 10MM
516 P0454Z516 FLAT WASHER 12MM 546 P0454Z546 LOCK NUT M12-1.75
517 P0454Z517 MOTOR 5HP 240V 1-PH 547 P0454Z547 HEX BOLT M10-1.5 X 55
517-1 P0454Z517-1 FAN COVER 548 P0454Z548 BRACKET
517-2 P0454Z517-2 MOTOR FAN 549 P0454Z549 PEDAL
517-3V2
P0454Z517-3V2
S CAPACITOR 300M 250V 549A P0454Z549A PEDAL ASSEMBLY
517-4V2
P0454Z517-4V2
R CAPACITOR 60M 450V 550V2 P0454Z550V2 MAGNETIC SWITCH MS1-35D V2.01.11
517-5 P0454Z517-5 MOTOR WIRING JUNCTION BOX 550V2-1 P0454Z550V2-1 MAG SWITCH COVER ASSY V2.07.12
517-6 P0454Z517-6 BALL BEARING 6206ZZ 550V2-2 P0454Z550V2-2 CONTACTOR NHD C-35D 220V
517-7 P0454Z517-7 BALL BEARING 6204ZZ 550-3 P0454Z550-3 OL RELAY NHD NTH-28 24-28A
517-8 P0454Z517-8 CENTRIFUGAL SWITCH 19MM 3450 551 P0454Z551 PHLP HD SCR M5-.8 X 20
517-9 P0454Z517-9 CONTACT PLATE 19MM 552 P0454Z552 FLAT WASHER 5MM
518 P0454Z518 KEY 5 X 5 X 30 553 P0454Z553 HEX NUT M5-.8
519 P0454Z519 FLAT WASHER 8MM 554 P0454Z554 FRONT COVER
520 P0454Z520 HEX NUT M8-1.25 555 P0454Z555 PHLP HD SCR M6-1 X 20
521 P0454Z521 HEX BOLT M8-1.25 X 45 556 P0454Z556 HEX BOLT M8-1.25 X 20
522 P0454Z522 STRAIN RELIEF 557 P0454Z557 SUPPORT ARM 26"
523 P0454Z523 HEX NUT M8-1.25 558 P0454Z558 HEX BOLT M6-1 X 16
524 P0454Z524 FLAT WASHER 8MM 559 P0454Z559 HEX BOLT M6-1 X 16
525 P0454Z525 SLEEVE 560 P0454Z560 BALL STRAIN RELIEF
526 P0454Z526 UNIVERSAL WHEEL 78MM DIA 561 P0454Z561 CONTROL BOX
527 P0454Z527 HEX BOLT M8-1.25 X 65 562 P0454Z562 CONTROL PANEL
528 P0454Z528 RUBBER FOOT 563V2 P0454Z563V2 START BUTTON CLEAR V2.01.11
528-1 P0454Z528-1 HEX NUT 3/8-16 565V2 P0454Z565V2 E-STOP BUTTON 3-ARROW V2.01.11
529 P0454Z529 EXT RETAINING RING 9MM 566 P0454Z566 TAP SCREW #10 X 3/8
530 P0454Z530 FLAT WASHER 12MM 567V2 P0454Z567V2 POWER CORD 12G 3W 72" L6-30P V2.08.12
