Cleaning
Sanding Belts
Figure 31. Table lift screws (2 of 4 shown).
Figure 32. Helical gear.
Model D3003 PRO-STIK
®
Cleaning Pad
Extend the life of your sandpaper! Just feed this
crepe-rubber cleaning pad through your drum
sander to remove dust build-up from the sand-
paper without damage. Measures 15" x 20" x
3
⁄4".
Figure 33. D3003 PRO-STIK
®
Cleaning Pad.
To increase the working life of your sanding belts,
clean them whenever they decrease in perfor-
mance due to heavy loading of material. Use a
Model D3003 PRO-STIK
®
Cleaning Pad as shown
in Figure 33.
To clean sanding belt:
1.
DISCONNECT MACHINE FROM POWER!
2. Set table to thickness of cleaning pad.
3. Connect machine to power, then run pad
through sander two or three times. DO NOT
take too deep of a cut—the belt should barely
touch cleaning pad!
Bushings
Oil Type ........................... Model T23964 NLGI#2
Oil Amount
..........................................As Needed
Check/Add Frequency
...........................6 Months
Lubricate the table lift screws, chain, and helical
gear with lithium grease every six months. Clean
the chain and table lift screws (see Figure 31),
then apply grease onto the chain links and screw
threads. Clean the helical gear (see Figure 32)
and place a dab of grease on the teeth. Move the
table up or down to spread the grease thoroughly
throughout the mechanism.
