Grizzly G0654 User Manual

Model G0654 (Mfg. Since 9/07)
-45-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0654001 BELT GUARD ASSEMBLY 45 P0654045 PUSH BLOCK HOLDER
2 PFB01M FLANGE BOLT M6-1 X 12 46 P0654046 BACK PANEL
3 PW03M FLAT WASHER 6MM 47 P0654047 MOTOR 1HP 110V
4 PN01M HEX NUT M6-1 47-1 P0654047-1 FAN COVER
5 PLW06M LOCK WASHER 10MM 47-2 P0654047-2 FAN
6 P0654006 SPECIAL STUD M10-1.5 47-3 P0654047-3 S CAPACITOR COVER
7 PN02M HEX NUT M10-1.5 47-4 PC200D S CAP 200M 125V 1-1/4 X 2-3/4
8 PB18 HEX BOLT 3/8-16 X 1 47-5 P0654047-5 JUNCTION BOX
9 PB02M HEX BOLT M6-1 X 12 48 PK12M KEY 5 X 5 X 30
10 P0654010 TOP PLATE ASSEMBLY 49 PVA36 V-BELT A-36 4L360
11 P0654011 DUST PORT 50 P0654050 MOTOR PULLEY
12 PFB01M FLANGE BOLT M6-1 X 12 51 PSS01M SET SCREW M6-1 X 10
13 PFS03 FLANGE SCREW 10-24 X 3/8 52 P0654052 POWER CORD 14AWG X 3C
14 P0654014 LEFT PANEL 53 P0654053 SWITCH CORD 16AWG X 3C
15 PCB06 CARRIAGE BOLT 5/16-18 X 1-1/4 56 PLN04M LOCK NUT M8-1.25
16 PW03M FLAT WASHER 6MM 57 P0654057 WHEEL
17 PN01M HEX NUT M6-1 58 P0654058 SLEEVE
18 P0654018 DUST CHUTE 59 PW01M FLAT WASHER 8MM
19 PW07 FLAT WASHER 5/16 60 PB86M HEX BOLT M8-1.25 X 65
20 PN02 HEX NUT 5/16-18 61 PB18 HEX BOLT 3/8-16 X 1
21 PW03M FLAT WASHER 6MM 62 PN08 HEX NUT 3/8-16
22 PN01M HEX NUT M6-1 63 P0654063 LEVELING FOOT
23 PW03M FLAT WASHER 6MM 64 P0654064 MOBILE BASE CHASSIS
24 PN01M HEX NUT M6-1 65 P0654065 PEDAL ASSEMBLY
25 P0654025 STRAIN RELIEF 6N-4 65-1 PEC10M E-CLIP 9MM
26 P0654026 SWITCH BOX 65-2 P0654065-2 SPECIAL BOLT
27 P0654027 STRAIN RELIEF 6N-4 65-3 P0654065-3 SPECIAL FLAT WASHER
28 PFS03 FLANGE SCREW 10-24 X 3/8 65-4 P0654065-4 SHAFT
29 P0654029 SWITCH BOX BRACKET 65-5 PB22M HEX BOLT M8-1.25 X 50
31 P0654031 SWITCH 65-6 PW01M FLAT WASHER 8MM
32 P0654032 SWITCH COVER 65-7 P0654065-7 SPECIAL HEX NUT M8
33 P0654033 CORD PLATE 65-8 PN02M HEX NUT M10-1.5
34 P0654034 SPECIAL SCREW M4-.7 X 20 65-9 PW04M FLAT WASHER 10MM
35 PFS03 FLANGE SCREW 10-24 X 3/8 65-10 PB45M HEX BOLT M8-1.25 X 100
36 PFS03 FLANGE SCREW 10-24 X 3/8 65-11 PW01M FLAT WASHER 8MM
37 P0654037 FRONT PANEL 65-12 P0654065-12 TROLLEY WHEEL
38 P0654038 BOTTOM PLATE 65-13 P0654065-13 SLEEVE
39 PFB01M FLANGE BOLT M6-1 X 12 65-14 P0654065-14 TROLLEY BRACKET
40 PTLW02M EXT TOOTH WASHER 5MM 65-15 PW04M FLAT WASHER 10MM
41 PS05M PHLP HD SCR M5-.8 X 8 65-16 P0654065-16 SPECIAL HEX NUT M10
42 P0654042 CABINET SUPPORT 65-17 PB144M HEX BOLT M10-1.5 X 55
43 P0654043 RIGHT PANEL 65-18 P0654065-18 PEDAL BRACKET
44 PFS03 FLANGE SCREW 10-24 X 3/8 65-19 P0654065-19 PEDAL
Stand Parts List
