Grizzly G0654 User Manual

Model G0654 (Mfg. Since 9/07)
-47-
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P0654101 GIB 145 PSS53M SET SCREW M5-.8 X 12
102 P0654102 KNIFE 147 P0654147 INDEX PIN M6-1 X 14
103 P0654103 GIB BOLT 148 P0654148 COMPRESSION SPRING
104 P0654104 CUTTERHEAD PULLEY 149 P0654149 PLUNGER HOUSING
105 P0654105 RIGHT HAND BEARING SUPPORT 150 P0654150 BALL KNOB M6-1
106 P6203 BALL BEARING 6203ZZ 151 P0654151 POINTER
107 PK12M KEY 5 X 5 X 30 152 PS17M PHLP HD SCR M4-.7 X 6
108 PSS53M SET SCREW M5-.8 X 12 153 P0654153 PLATE
109 P0654109 SPECIAL NUT 154 P0654154 TORSION SPRING
110 PSS01M SET SCREW M6-1 X 10 155 P0654155 CUP
111 P0654111 CUTTERHEAD 156 P0654156 RETAINER
112 P6202 BALL BEARING 6202ZZ 157 PS01M PHLP HD SCR M4-.7 X 18
113 P0654113 LEFT HAND BEARING SUPPORT 158 P0654158 BLOCK ASSEMBLY
114 P0654114 SPECIAL STUD 161 P0654161 LOCK LEVER M6-1 X 30
115 PLW06M LOCK WASHER 10MM 162 PSBS23M BUTTON HD CAP SCR M8-1.25 X 25
116 PN02M HEX NUT M10-1.5 163 PW01M FLAT WASHER 8MM
117 P0654117 FENCE CARRIAGE 164 P0654164 ALIGNMENT PIN
118 PW04M FLAT WASHER 10MM 165 P0654165 BRACKET
119 PLW06M LOCK WASHER 10MM 166 PSB11M CAP SCREW M8-1.25 X 16
120 PB01M HEX BOLT M10-1.5 X 30 167 PLW04M LOCK WASHER 8MM
121 PRP39M ROLL PIN 4 X 20 168 PEC07M E-CLIP 7MM
122 P0654122 SPECIAL KEY 9.5 X 9.5 X 128 169 P0654169 LINK
123 P0654123 LOCK SCREW ASSEMBLY 170 P0654170 SPECIAL BOLT
124 PN01M HEX NUT M6-1 172 P0654172 JOINTER TABLE ASSEMBLY
125 PSS12M SET SCREW M6-1 X 25 176 PN09M HEX NUT M12-1.75
126 P0654126 GIB 177 P0654177 INFEED TABLE ADJUSTMENT LEVER
127 P0654127 PUSH BLOCK 179 PSS20M SET SCREW M8-1.25 X 8
128 PSS02M SET SCREW M6-1 X 6 180 P0654180 BLOCK
129 P0654129 SPECIAL WASHER 181 P0654181 SHAFT
130 PS14M PHLP HD SCR M6-1 X 12 182 PEC12M E-CLIP 12MM
131 PW03M FLAT WASHER 6MM 184 P0654184 SEAL
133 P0654133 HANDWHEEL 187 PWR810 WRENCH 8 X10
134 P0654134 HANDLE 188 PRW1214 WRENCH 12 X 14
135 P0654135 SHOULDER SCREW 189 PWR1417 WRENCH 14 X 17
136 P0654136 COLLAR 190 PAW02.5M HEX WRENCH 2.5MM
137 P0654137 SPECIAL WASHER 191 PAW03M HEX WRENCH 3MM
138 P0654138 BLOCK 192 PAW04M HEX WRENCH 4MM
139 PLW04M LOCK WASHER 8MM 193 PAW06M HEX WRENCH 6MM
140 PSB05M CAP SCREW M8-1.25 X 50 195 P0654195 KNIFE GAUGE ASSEMBLY
141 P0654141 SCREW SHAFT 195-1 P0654195-1 KNIFE GAUGE ROD
143 P0654143 GUARD SHAFT 195-2 P0654195-2 KNIFE GAUGE BLOCK
144 P0654144 GUARD 195-3 PEC015M E-CLIP 8MM
