Model G0654 (Mfg. Since 9/07)

-49-

REF PART # DESCRIPTION REF PART # DESCRIPTION

201 P0654201 FENCE 221 PN03M HEX NUT M8-1.25

203 P0654203 BALL KNOB M10-1.5 222 P0654222 ALIGNMENT PIN 7 X 24

204 P0654204 STUD M10-1.5 223 P0654223 LEFT BRACKET

205 P0654203 BALL KNOB M10-1.5 224 P0654224 SPECIAL SCREW M8-1.25

206 P0654204 STUD M10-1.5 225 P0654225 SPECIAL FLAT WASHER

207 P0654207 FENCE LOCK HANDLE SHAFT 226 P0654226 LEVER ASSY M8-1.25

208 P0654208 FENCE LOCK HANDLE BOLT M12-1.75 227 P0654227 RIGHT BRACKET

209 PW06M FLAT WASHER 12MM 228 PS14M PHLP HD SCR M6-1 X 12

210 P0654210 SPECIAL NUT M12 229 PW03M FLAT WASHER 6MM

211 P0654211 FENCE SLIDE BRACKET 230 P0654230 REAR GUARD BASE

212 PSS04M SET SCREW M6-1 X 12 231 P0654231 REAR GUARD TOP

213 PN03M HEX NUT M8-1.25 232 PN35M ACORN NUT M6-1

214 PB26M HEX BOLT M8-1.25 X 30 233 PW03M FLAT WASHER 6MM

215 P0654215 BRACKET 234 P0654234 EXTENSION SPRING

216 PSB155M CAP SCREW M8-1.25 X 14 235 PB10M HEX BOLT M6-1 X 25

217 PW01M FLAT WASHER 8MM 236 PN01M HEX NUT M6-1

218 P0654218 SUPPORT BRACKET 237 P0654237 SHAFT LOCK M6-1

219 P0654219 ALIGNMENT PIN 7 X 24 238 P0654238 BALL KNOB M6-1

220 PB26M HEX BOLT M8-1.25 X 30 239 PSS26M SET SCREW M5-.8 X 6

Fence Parts List
