Inventory
Box 1 Contents (Figures 9 –11) Qty
A. Main Table Saw Unit .................................. 1
B. Access Panel .............................................. 1
C. Motor Cover ................................................ 1
D. Extension Wings ........................................ 2
E. Blade Guard Assembly .............................. 1
F. Table Insert ................................................. 1
G. Dado Insert ................................................. 1
H. Saw Blade 10" x 40T .................................. 1
I. Spreader/Riving Knife................................. 1
J. Push Stick .................................................. 1
K. Wrench 23mm Closed, 22mm Open .....1 Ea
L. Miter Gauge ................................................ 1
M. Miter Gauge Handle ................................... 1
N. Handwheels ................................................ 2
O. Star Knobs.................................................. 2
P. Fence Rail End Caps ................................. 4
Q. Hex Wrenches 2.5, 3, 4, 5, 6, 8mm ......1 Ea
R. Dust Port 4" ................................................ 1
Box 2 Contents (Figure 12) Qty
S. Fence Assembly ......................................... 1
T. Front Fence Rail ......................................... 1
U. Rear Fence Rail ......................................... 1
Figure 10. Extension wings and access panel.
B
D
C
Fasteners (see Hardware Recognition Chart)
Cap Screws M10-1.5 x 30 ................................. 6
Cap Screws M8-1.25 x 25 ................................. 8
Hex Bolts M8-1.25 x 30 ..................................... 8
Hex Bolts M8-1.25 x 16 ..................................... 2
Hex Nuts M8-1.25 ............................................ 14
Flat Washers 10mm .......................................... 6
Lock Washers 10mm ......................................... 6
Lock Washers 8mm ........................................... 2
Flat Washers 5mm .......................................... 16
Button Head Cap Screws M5-.8 x 16 .............. 16
Tap Screws 3.5 x 9.5 V2.06.19 .......................... 2
Flat Washer 6 x 20mm ...................................... 1
Set Screws M8-1.25 x 10 ................................... 6
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Figure 12. Fence assembly and fence rails.
T
U
S
Figure 9. Main table saw unit.
A
Figure 11. Component inventory.
M
E
F
G
I
K
J
L
H
Q
P
O
N
R
