Model G0771Z (Mfd. Since 01/21)
-3-
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
Figure 1. Model G0771Z identification of main controls and components.
Left
Extension
Wing
Fence
Right
Extension
Wing
Scale
Front
Fence
Rail
Blade Tilt
Handwheel
4" Dust
Port
Blade Tilt
Scale
Blade Height
Handwheel
Blade
Height Lock
Rear
Fence
Rail
ON/OFF
Switch
Blade
Tilt Lock
Blade Guard
Motor Cover
Fence Lock
Handle
Miter
Gauge
Identification
For Your Own Safety Read Instruction Manual Before Operating Saw
a) Wear eye protection.
b) Use saw-blade guard and spreader for every operation for which it can be used, including all
through sawing.
c) Keep hands out of the line of saw blade.
d) Use a push-stick when required.
e) Pay particular attention to instructions on reducing risk of kickback.
f) Do not perform any operation freehand.
g) Never reach around or over saw blade.
