G0803 (Mfd. Since 09/15)
Main Parts List (Continued)
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P0803101 QUICK-RELEASE LEVER HUB 130 P0803130 WRENCH 8 X 10MM OPEN-ENDS
102 P0803102 SET SCREW M5-.8 X 6 131 P0803131 HEX WRENCH 6MM
103 P0803103 QUICK-RELEASE LEVER 8 X 95 132 P0803132 PUSH STICK
104 P0803104 MITER GAUGE ASSEMBLY 133 P0803133 STORAGE HOOK M6-1
105 P0803105 TABLE INSERT 135 P0803135 FENCE BODY
106 P0803106 TABLE 137 P0803137 END CAP 25 X 52
108 P0803108 HEX BOLT M6-1 X 22 138 P0803138 SPACER PLATE
109 P0803109 BEVEL CASTING 140 P0803140 FENCE BASE
111 P0803111 CAP SCREW M8-1.25 X 14 141 P0803141 SHAFT 8 X 77
112 P0803112 GUIDE BUSHING 142 P0803142 FENCE HANDLE LOCKING CAM
113 P0803113 CAP SCREW M6-1 X 12 143 P0803143 FENCE HANDLE M6-1 X 10
115 P0803115 ADJUSTABLE HANDLE M8-1.25 X 25 144 P0803144 PHLP HD SCR M5-.8 X 6
116 P0803116 BEVEL INDICATOR 145 P0803145 SPRING PLATE
119 P0803119 GEARED KNOB 12T, 12L X 40D 147 P0803147 GUIDE RAIL CAP (LEFT)
120 P0803120 COMPRESSION SPRING 0.7 X 9.8 X 25 148 P0803148 GUIDE RAIL
121 P0803121 SHOULDER SCREW M5-.8 X 10, 8 X 39 149 P0803149 FENCE RAIL KNOB M6-1 X 16
122 P0803122 MOTOR 1/3 HP 120V 1-PH 150 P0803150 FENCE RAIL KNOB M6-1 X 24
122-1 P0803122-1 MOTOR FAN COVER 151 P0803151 GUIDE RAIL CAP (RIGHT)
122-2 P0803122-2 MOTOR FAN 152 P0803152 "D" NUT M6-1
122-3 P0803122-3 CAPACITOR COVER 153 P0803153 HEX NUT M4-.7
122-4 P0803122-4 R CAPACITOR 30M 250V 1-1/2 X 2 155 P0803155 LED DRIVER HOPESTAR LED-5V700 120V 5.5W
122-5 P0803122-5 BALL BEARING 6201ZZ (REAR) 156 P0803156 CAP SCREW M4-.7 X 12
122-6 P0803122-6 BALL BEARING 6202ZZ (FRONT) 158 P0803158 WORK LAMP ASSEMBLY
123 P0803123 GASKET 159 P0803159 BULB LED 5.5W 2V PUSH-IN
124 P0803124 MOTOR PULLEY 160 P0803160 HEX WRENCH 4MM
128 P0803128 CAP SCREW M8-1.25 X 25 161 P0803161 HEX WRENCH 2.5MM
129 P0803129 POWER CORD 18G 3W 72" 5-15P 162 P0803162 MOTOR CORD 18G 3W 12"
To Next Page
