Grizzly G0803 User Manual

G0803 (Mfd. Since 09/15)
-51-
Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0803001 KNOB M8-1.25 X 25, DIA 50, 5-LOBE 45 P0803045 WHEEL BRUSH
2 P0803002 FLAT WASHER 8MM 46 P0803046 CARRIAGE BOLT M8-1.25 X 65
3 P0803003 COMPRESSION SPRING 2.5 X 14 X 64 47 P0803047 RUBBER FOOT
4 P0803004 CARRIAGE BOLT M8-1.25 X 80 48 P0803048 TIMING BELT 130L036
5 P0803005 WHEEL ADJUSTMENT BRACKET 49 P0803049 DUST PORT 2"
6 P0803006 CAP SCREW M5-.8 X 8 50 P0803050 PHLP HD SCR M5-.8 X 8
7 P0803007 QUICK-RELEASE PIVOT SHAFT 8 X 90 52 P0803052 DOOR LOCK CAM KNOB
8 P0803008 EXT RETAINING RING 8MM SELF-LOCKING 54 P0803054 BEARING RETAINER SCREW M5-.8 X 15
9 P0803009 HEX NUT M10-1.5 55 P0803055 BALL BEARING 606ZZ
10 P0803010 LOCK WASHER 10MM 56 P0803056 FLAT WASHER 5MM
11 P0803011 WHEEL MOUNT PLATE 57 P0803057 LOWER GUIDE ROD
12 P0803012 WHEEL SHAFT (UPPER) 58 P0803058 CAP SCREW M5-.8 X 14
13 P0803013 BALL BEARING 6000ZZ 59 P0803059 BALL BEARING 605ZZ
14 P0803014 WHEEL 9" 61 P0803061 LOWER GUIDE
15 P0803015 INT RETAINING RING 26MM 62 P0803062 SQUARE NUT M5-.8
16 P0803016 EXT RETAINING RING 10MM 63 P0803063 LOWER GUIDE BLOCK
17 P0803017 TIRE 9" 64 P0803064 CAP SCREW M5-.8 X 12
18 P0803018 WHEEL COVER (UPPER) 65 P0803065 FLAT WASHER 6MM
19 P0803019 BLADE 62" X 3/8" X 0.025" 10 TPI RAKER 66 P0803066 CAP SCREW M6-1 X 10
20 P0803020 WHEEL COVER (LOWER) 67 P0803067 LOWER BLADE COVER
21 P0803021 LOCK NUT M6-1 68 P0803068 FLAT WASHER 4MM
22 P0803022 BUSHING 69 P0803069 PHLP HD SCR M4-.7 X 10
23 P0803023 CAP SCREW M6-1 X 16 70 P0803070 STRAIN RELIEF M16-2 TYPE-3
25 P0803025 TAP SCREW M5 X 14 71 P0803071 GUIDE PLATE
26 P0803026 WHEEL PULLEY 72 P0803072 SET SCREW M4-.7 X 6
27 P0803027 WHEEL SHAFT (LOWER) 73 P0803073 PINION
28 P0803028 HEX NUT M6-1 74 P0803074 ADJUSTMENT KNOB SEAT
29 P0803029 HEX BOLT M6-1 X 16 76 P0803076 CAP SCREW M5-.8 X 10
30 P0803030 LOCK NUT M12-1.75 77 P0803077 KNOB W/SHAFT 6 X 22, DIA 32, 6-LOBE
31 P0803031 LIFTING HANDLE 78 P0803078 UPPER GUIDE
32 P0803032 PHLP HD SCR M6-1 X 10 79 P0803079 UPPER GUIDE ROD
33 P0803033 FRAME 82 P0803082 CAP SCREW M5-.8 X 16
34 P0803034 WIRE CONNECTOR 85 P0803085 UPPER BLADE COVER ASSEMBLY
35 P0803035 SWITCH MOUNTING PLATE 86 P0803086 SQUARE NUT M8-1.25
36 P0803036 PHLP HD SCR M5-.8 X 10 87 P0803087 UPPER GUIDE BLOCK
37 P0803037 PADDLE SWITCH W/KEY GRIZZLY G8988 91 P0803091 KNOB BOLT M8-1.25 X 14, DIA 32, 6-LOBE
38 P0803038 ROCKER SWITCH GORBO XCK-017 10(4) A 93 P0803093 COMPRESSION SPRING 1 X 13 X 18
39 P0803039 LOCK WASHER 5MM 94 P0803094 KNOB BOLT M8-1.25 X 35, DIA 32, 6-LOBE
40 P0803040 EXT TOOTH WASHER 5MM 96 P0803096 RELEASE WHEEL
42 P0803042 HEX NUT M8-1.25 99 P0803099 QUICK-RELEASE MOUNT BRACKET
44 P0803044 SPACER 100 P0803100 WAVY WASHER 19MM
