Grizzly G1033X User Manual

Model G1033/X/Z (Mfd. Since 02/19)
-49-
READ ELECTRICAL SAFETY
ON PAGE 48!
Hot
Hot
Ground
220 VAC
6-20 Plug
220
VAC
G
The motor wiring shown here is
current at the time of printing, but it
may not match your machine.
Always use the wiring diagram
inside the motor junction box.
A
96
98
1/2
T1/2 T3/6
NO14
3/4
T2/4
L1/1 L3/5
NO13
L2/3
5/6
95
18
ARC
AMP
26
22
NC21
SDE
NC22
Ground
RESET
MAGNETIC SWITCH
ASSEMBLY SDE MP-18
SDE
MA-18
240V
RA-30
B
GND
Start Capacitor
MOTOR (220V)
600MFD
125VAC
G1033 Wiring Diagram
