Model G1033/X/Z (Mfd. Since 02/19)
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G1033, G1033X, G1033Z PLANERS
Model Number G1033 G1033X G1033Z
Product Dimensions
Weight
702 lbs. 775 lbs 702 lbs.
Width (side-to-side) x Depth
(front-to-back) x Height
39" x 58" x 41" 39" x 56" x 41" 39" x 58" x 41"
Foot Print (Length x Width) 22" x 28"
Shipping Dimensions
Type Wood Crate
Weight 820 lbs. 909 lbs. 820 lbs.
Width (side-to-side) x Depth
(front-to-back) x Height
38" x 30" x 46" 45" x 30" x 46" 38" x 30" x 46"
Electrical
Power Requirement 220V, Single-Phase, 60 Hz
Full-Load Current Rating 18A 28A 23A
Minimum Circuit Size 20A 30A
Connection Type Cord & Plug
Power Cord Included Yes
Power Cord Length 10'
Power Cord Gauge 12 AWG 10 AWG 12 AWG
Plug Included Yes No Yes
Included Plug Type 6-20 N/A L6-30
Switch Type
Magnetic Switch w/Thermal
Overload Protection
Button Controls w/
Magnetic Switch Protection
Magnetic Switch w/Thermal
Overload Protection
Motor
Type TEFC Capacitor-Start Induction
Horsepower 3 HP 5 HP
Phase Single-Phase
Amps 18A 28A 23A
Speed 3450 RPM
Power Transfer Triple V-Belt Drive
Bearings Shielded & Permanently Lubricated
Manufacturer Specifications
Country of Origin Taiwan
Warranty 1 Year
Approx. Assembly & Setup Time 30 Minutes
Serial Number Location ID Label on Upper Cover
ISO 9001 Factory Yes
NRTL Certified Yes No Yes
