Grizzly G1033X User Manual

Model G1033/X/Z (Mfd. Since 02/19)
-7-
Model Number G1033 G1033X G1033Z
Main Specifications
Planer Size 20"
Max. Cut Width 20"
Max. Stock Thickness 8"
Min. Stock Thickness
1
⁄4"
Min. Stock Length 7"
Number of Cuts Per Inch 104, 83
Number of Cuts Per Minute 20,000
Cutterhead Speed 5000 RPM
Planing Feed Rate 16, 28 FPM
Max. Cut Depth Planing Full
Width
3
⁄32"
5
⁄64"
3
⁄32"
Max. Cut Depth Planing 6-Inch
Wide Board
1
⁄8"
Dust Port Size 5"
Cutterhead Info
Cutterhead Type 4-Knife Spiral 4-Knife
Cutterhead Diameter 3
1
⁄4"
Number of Knives 4 N/A 4
Knife Type HSS, Single-Sided, Solid N/A HSS, Single-Sided, Solid
Knife Length 20" N/A 20"
Knife Width 1" N/A 1"
Knife Thickness
1
⁄8" N/A
1
⁄8"
Knife Adjustment Springs or Jack Screws N/A Springs or Jack Screws
Number of Spirals N/A 4 N/A
Number of Indexable Cutters N/A 92 N/A
Cutter Insert Type N/A Indexable Carbide N/A
Cutter Insert Length N/A 15mm N/A
Cutter Insert Width N/A 15mm N/A
Cutter Insert Thickness N/A 2.5mm N/A
Table Info
Table Movement 8"
Table Bed Length 58" 56" 58"
Table Bed Width 25
3
⁄4" 20" 25
3
⁄4"
Table Bed Thickness 2
1
⁄2" 2
1
⁄4" 2
1
⁄2"
Floor-to-Table Height 22
1
⁄2" – 31" 26" – 34" 22
1
⁄2" – 31"
Construction
Table Precision-Ground Cast Iron
Body Cast Iron
Stand Steel
Cutterhead Assembly Steel
Infeed Roller Serrated Steel
Outfeed Roller Smooth Steel
Paint Type/Finish Powder Coated
