G1033/G1033Z Labels & Cosmetics
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
grizzly.com
G1033
G1033Z
Only shift gearbox when
planer is running.
Neutral
28 FPM
16 FPM
709
703
700V3
704
705
701
702
706
707V2
708
711
712
710
WARNING!
EYE/EAR/LUNG
INJURY HAZARD!
Always wear safety
glasses, ear protection,
and respirator when
using this machine.
INJURY/SHOCK
HAZARD!
Disconnect power
before adjustments,
maintenance, or
service.
MODEL G1033
20" SPIRAL CUTTERHEAD PLANER
Motor: 3 HP, 230V, 1-Ph, 60 Hz
Full-Load Current Rating: 18A
Cutterhead: 4 Spirals, 52 Inserts
Cutterhead Speed: 5000 RPM
Feed Rates: 16 & 20 FPM
Maximum Depth of Cut: 1/8"
Minimum Stock Thickness: 3/16"
Minimum Stock Length: 6"
Maximum Cutting Width: 15"
Maximum Cutting Height: 6"
Weight: 520 lbs.
Specifications
WARNING!
Date
Mfd. for Grizzly in Taiwan
S/N
To reduce the risk of serious injury when using this machine:
1. Read and understand owner’s manual before operating.
2. Always wear approved safety glasses and respirator.
3. Disconnect power before doing any service on machine.
4. Only plug power cord into a grounded outlet.
5. Do not wear loose clothing, gloves, jewelry, or other
items that can get entangled.
6. Do not plane two boards of varying thickness at the same
time.
7. Never plane material smaller than 6" long or
3
/
16
" thick.
8. Keep fingers clear of pinch point between stock and
table.
9. Stand clear of board ends during cutting operation.
10. Inserts are sharp! Use extreme caution when servicing.
11. Never reach into cutting area while machine is running.
12. Do not expose to rain or use in wet locations.
13. Prevent unauthorized use by children or untrained users.
175370
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual, call
(800) 523-4777 or go to
www.grizzly.com.
Note: Similar model headstock
shown as example.
Add SAE 30 oil every 24 hours of operation.
NOTICE
INJURY HAZARD!
To reduce the risk of serious personal
injury, do not remove this cover while the
machine is running or connected to power.
Always disconnect power before servicing.
REF PART # DESCRIPTION REF PART # DESCRIPTION
700V3 P1033700V3 MACHINE ID LABEL V3.02.19 (G1033) 707V2 P1033707V2 SHIFT GEARBOX NOTICE V2.02.19
700V3 P1033Z700V3 MACHINE ID LABEL V3.02.19 (G1033Z) 708 P1033708 MODEL NUMBER LABEL (G1033)
701 P1033701 READ MANUAL LABEL 708 P1033Z708 MODEL NUMBER LABEL (G1033Z)
702 P1033702 EYE/EAR/LUNG INJURY LABEL 709 P1033709 TOUCH-UP PAINT, GRIZZLY PUTTY
703 P1033703 ELECTRICITY LABEL 710 P1033710 TOUCH-UP PAINT, GRIZZLY GREEN
704 P1033704 BELT COVER WARNING LABEL 711 P1033711 GRIZZLY.COM LABEL
705 P1033705 DISCONNECT POWER LABEL 712 P1033712 GRIZZLY NAMEPLATE-LARGE
706 P1033706 ADD OIL NOTICE
