Grizzly G1033X User Manual

Model G1033/X/Z (Mfd. Since 02/19)
-61-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1033/G1033Z Table & Base Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P1033201 MAIN TABLE 307 P1033307 LEADSCREW NUT 19.05-4
202 P1033202 MAIN TABLE ROLLER 308 P1033308 SPACER
203 P1033203 BALL BEARING 6201-2RS 309 P1033309 INT RETAINING RING 38MM
204 P1033204 ECCENTRIC SHAFT 310 P1033310 KEY 4 X 4 X 10
205 P1033205 SET SCREW M6-1 X 12 311 P1033311 GEAR 24T
206 P1033206 THREADED GIB 312 P1033312 EXT RETAINING RING 12MM
207 P1033207 LOCKING ROD 313 P1033313 BALL BEARING 6202-2RS
208 P1033208 GIB 314 P1033314 INT RETAINING RING 35MM
209 P1033209 KNOB 6-LOBE M12-1.75, D53 316 P1033316 SPROCKET 10T
210 P1033210 CAP SCREW M8-1.25 X 16 317 P1033317 FLAT WASHER 10MM
211 P1033Z211 EXT ROLLER BRACKET (G1033Z) 318 P1033318 HEX NUT M10-1.25
211V2 P1033211V2 EXT ROLLER BRACKET V2.03.05 (G1033) 319 P1033319 SPACER 8.2 X 22 X 3MM
212V2 P1033Z212V2 EXTENSION TABLE ROLLER V2.05.18 (G1033Z) 320 P1033320 HEX BOLT M8-1.25 X 25
212V4 P1033212V4 EXTENSION TABLE ROLLER V4.05.18 (G1033) 321 P1033321 IDLER BRACKET
213 P1033213 HEX BOLT M10-1.5 X 25 322 P1033322 IDLER SHAFT
214 P1033214 FENDER WASHER 13MM 323 P1033323 SPROCKET 10T
218 P1033218 HEX BOLT M6-1 X 12 324 P1033324 EXT RETAINING RING 15MM
219 P1033219 FLAT WASHER 8MM 325 P1033325 CHAIN #40 X 166
220 P1033220 EXTENSION ROLLER AXLE 326 P1033326 LIFTING BAR
221 P1033221 EXTENSION ROLLER BUSHING, PLASTIC 327 P1033327 EXT RETAINING RING 17MM
301 P1033301 BASE 328 P1033328 DUST BOOT FLANGE
302 P1033302 SET SCREW M10-1.5 X 12 329 P1033329 TAP SCREW M5 X 10
303 P1033303 COLUMN, SECONDARY 330 P1033330 DUST BOOT
304 P1033304 COLUMN, PRIMARY 335 P1033335 DUST BOOT FLANGE RING
305 P1033305 LEADSCREW 19.05-4 X 321, SECONDARY 336 P1033336 TAP SCREW M5 X 16
306 P1033306 LEADSCREW 19.05-4 X 335, PRIMARY
