Grizzly G1033X User Manual

Model G1033/X/Z (Mfd. Since 02/19)
-51-
READ ELECTRICAL SAFETY
ON PAGE 48!
G1033X Wiring Diagram
Ground
START STOP POWER
CONTROL PANEL (viewed from behind)
PEDESTAL
G
X
Y
The motor wiring shown here is
current at the time of printing, but it
may not match your machine.
Always use the wiring diagram
inside the motor junction box.
A
96
98
1/2
U/2/T1 W/6/T3
NC22
3/4
V/4/T2
R/1/L1 T/5/L3
NC21
S/3/L2
5/6
95
22
ARC
AMP
34
28
NO13
NO14
Ground
RESET
MAGNETIC SWITCH
ASSEMBLY MPE-30
SDE
MA-30
240V
RA-30
Hot
Hot
Ground
220
VAC
B
GND
Start Capacitor
800MFD
250VAC
50uF
350VAC
Run Capacitor
MOTOR (220V)
220 VAC
L6-30 PLUG
