Grizzly G1033X User Manual

Model G1033/X/Z (Mfd. Since 02/19)
-59-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1033/G1033Z Stand & Motor Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
15 P1033015 FENDER WASHER 8 X 30 X 4MM 414V2-4 P1033Z414V2-4 MOTOR JUNCTION BOX (G1033Z)
17 P1033017 MOTOR PULLEY (G1033) 414V2-5 P1033414V2-5 MOTOR FAN (G1033)
17 P1033Z017 MOTOR PULLEY (G1033Z) 414V2-5 P1033Z414V2-5 MOTOR FAN (G1033Z)
331 P1033331 HEX BOLT M12-1.75 X 50 414V2-6 P1033Z414V2-6 R CAPACITOR 60M 350V 1-3/4 X 4-5/16 (G1033Z)
332 P1033332 FLAT WASHER 12MM 414V2-7 P1033414V2-7 S CAPACITOR 600M 125V 1-3/4 X 3-5/16 (G1033)
334 P1033334 HEX NUT M12-1.75 414V2-7 P1033Z414V2-7 S CAPACITOR 600M 125V 1-3/4 X 3-5/16 (G1033Z)
401 P1033401 STAND 414V2-8 P1033414V2-8 CONTACT PLATE (G1033)
402 P1033402 MOTOR ACCESS PANEL 414V2-8 P1033Z414V2-8 CONTACT PLATE (G1033Z)
403 P1033403 FLAT HD SCR M6-1 X 20 414V2-9 P1033414V2-9 BALL BEARING 6205ZZ (FRONT) (G1033)
404 P1033404 PLATE CONNECTING ROD 414V2-9 P1033Z414V2-9 BALL BEARING 6205ZZ (FRONT) (G1033Z)
405 P1033405 MOTOR MOUNT PLATE 414V2-10 P1033414V2-10 BALL BEARING 6203ZZ (REAR) (G1033)
406 P1033406 SET SCREW M8-1.25 X 12 414V2-10 P1033Z414V2-10 BALL BEARING 6203ZZ (REAR) (G1033Z)
407 P1033407 COLLAR 414V2-11 P1033414V2-11 CENTRIFUGAL SWITCH (G1033)
408 P1033408 ROD END BOLT M12-1.75 X 105, ID 20MM 414V2-11 P1033Z414V2-11 CENTRIFUGAL SWITCH (G1033Z)
409 P1033409 HEX NUT M12-1.75 415V2 P1033415V2 KEY 5 X 5 X 30 V2.05.18
410 P1033410 FLAT WASHER 12MM 418 P1033418 STRAIN RELIEF TYPE-3 M25-1.5
411 P1033411 HEX BOLT M8-1.25 X 40 419 P1033419 FLAT WASHER 8MM
412 P1033412 FENDER WASHER 8 X 22 X 3MM 420 P1033420 STRAIN RELIEF TYPE-3 M25-1.5
413 P1033413 HEX NUT M8-1.25 421 P1033421 HEX WRENCH 3MM
414V2 P1033414V2 MOTOR 3HP 230V 1-PH V2.05.18 (G1033) 422 P1033422 HEX WRENCH 4MM
414V2 P1033Z414V2 MOTOR 5HP 230V 1-PH V2.05.18 (G1033Z) 423 P1033423 HEX WRENCH 5MM
414V2-1 P1033414V2-1 MOTOR FAN COVER (G1033) 424 P1033424 HEX WRENCH 6MM
414V2-1 P1033Z414V2-1 MOTOR FAN COVER (G1033Z) 425 P1033425 FLAT WRENCH 10 X 13MM OPEN-ENDS
414V2-2 P1033Z414V2-2 CAPACITOR COVER (RUN) (G1033Z) 426 P1033426 WRENCH 12 X 14MM OPEN-ENDS
414V2-3 P1033414V2-3 CAPACITOR COVER (START) (G1033) 427 P1033427 WRENCH 17 X 19MM OPEN-ENDS
414V2-3 P1033Z414V2-3 CAPACITOR COVER (START) (G1033Z) 428 P1033428 SET SCREW M8-1.25 X 16
414V2-4 P1033414V2-4 MOTOR JUNCTION BOX (G1033) 429 P1033429 HEX BOLT M8-1.25 X 30
