Grizzly G1033X User Manual

Model G1033/X/Z (Mfd. Since 02/19)
-67-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1033X Stand & Motor Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
19 P1033X019 FLANGE SCREW M6-1 X 12 169V5 P1033X169V5 MOTOR 5HP 220V 1-PH V5.03.18
39 P1033X039 MAGNETIC SWITCH SDE MPE-30 169V5-1 P1033X169V5-1 MOTOR JUNCTION BOX
39-1 P1033X039-1 CONTACTOR SDE MA-30 220V 169V5-2 P1033X169V5-2 MOTOR FAN COVER
39-2 P1033X039-2 MAGNETIC SWITCH COVER (FRONT) 169V5-3 P1033X169V5-3 MOTOR FAN
39-3V3 P1033X039-3V3 OL RELAY SDE RA-30 22-34A V3.03.18 169V5-4 P1033X169V5-4 S CAPACITOR 800M 250V
39-4 P1033X039-4 MAGNETIC SWITCH COVER (REAR) 169V5-5 P1033X169V5-5 R CAPACITOR 50M 350V
92 P1033X092 FOOT 169V5-6 P1033X169V5-6 CENTRIFUGAL SWTICH
120 P1033X120 FLAT HD SCR M6-1 X 20 169V5-7 P1033X169V5-7 MOTOR LABEL
121 P1033X121 MOTOR ACCESS PANEL 169V5-8 P1033X169V5-8 CAPACITOR BOX
122 P1033X122 CABINET STAND 170 P1033X170 PLATE CONNECTING ROD
123 P1033X123 CABINET STAND FRONT COVER 182 P1033X182 SET SCREW M8-1.25 X 20 (NYLOCK)
124 P1033X124 HEX NUT M5-.8 191 P1033X191 FLAT WASHER 8MM
125 P1033X125 STRAIN RELIEF TYPE-3 M25-1.5 202 P1033X202 PHLP HD SCR M4-.7 X 10
126 P1033X126 START SWITCH 220 P1033X220 STRAIN RELIEF TYPE-3 PG16
127 P1033X127 E-STOP BUTTON RENY R9C01VN 221 P1033X221 POWER CORD 10G 3W
128 P1033X128 POWER INDICATOR LIGHT 220V 22MM RED 222 P1033X222 STRAIN RELIEF TYPE-3 PG21
129 P1033X129 SWITCH PANEL 223 P1033X223 EXT TOOTH WASHER 5MM
130 P1033X130 SWITCH BOX 224 P1033X224 PHLP HD SCR M5-.8 X 10
131 P1033X131 SWITCH PEDESTAL 225 P1033X225 PHLP HD SCR M5-.8 X 15
132 P1033X132 PHLP HD SCR M5-.8 X 10 226 P1033X226 SWITCH PANEL
133 P1033X133 FLAT WASHER 12MM 227 P1033X227 MOTOR CORD 10G 3W 57"
162 P1033X162 MOTOR MOUNT PLATE 228 P1033X228 SWITCH CORD 18G 4W
163 P1033X163 COLLAR 231V2 P1033X231V2 MOTOR PULLEY V2.04.10
164 P1033X164 HEX BOLT M8-1.25 X 40 232 P1033X232 KEY 8 X 7 X 55
165 P1033X165 HEX NUT M8-1.25 235 P1033X235 SET SCREW M6-1 X 16
166 P1033X166 FLAT WASHER 8MM 236 P1033X236 SET SCREW M8-1.25 X 12
167 P1033X167 HEX NUT M12-1.75 237 P1033X237 HEX NUT M12-1.75
168 P1033X168 ROD END BOLT M12-1.75 X 120, 25.4 238 P1033X238 HEX NUT M6-1
