Grizzly G1033X User Manual

Model G1033/X/Z (Mfd. Since 02/19)
-69-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1033X Table & Base Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
107 P1033X107 EXTENSION WING 150 P1033X150 PHLP HD SCR M5-.8 X 10
108 P1033X108 HEX BOLT M8-1.25 X 25 151 P1033X151 DUST BOOT FLANGE
109 P1033X109 SET SCREW M8-1.25 X 12 152 P1033X152 COLUMN, PRIMARY
110 P1033X110 THREADED GIB 153 P1033X153 EXT RETAINING RING 17MM
111 P1033X111 LOCK ROD 154 P1033X154 LIFTING BAR
112 P1033X112 CAP SCREW M8-1.25 X 16 155 P1033X155 DUST BOOT FLANGE RING
113 P1033X113 ECCENTRIC SHAFT 156 P1033X156 WORM GEAR
114 P1033X114 MIDDLE TABLE 157 P1033X157 INT RETAINING RING 38MM
115 P1033X115 GIB 158 P1033X158 BUSHING 14 X 20
118 P1033X118 TABLE ROLLER 160 P1033X160 LEADSCREW M10 X 1.25 X 582, PRIMARY
119 P1033X119 LOCK HANDLE M12-1.75 161 P1033X161 PHLP HD SCR M5-.8 X 8
134 P1033X134 HEX BOLT M12-1.75 X 50 183 P1033X183 HEX WRENCH 3MM
135 P1033X135 LEADSCREW NUT 15.5 X 41.5 184 P1033X184 HEX WRENCH 4MM
136 P1033X136 LEADSCREW M10 X 1.25 X 400, SECONDARY 185 P1033X185 HEX WRENCH 5MM
137 P1033X137 COLUMN, SECONDARY 186 P1033X186 HEX WRENCH 6MM
138 P1033X138 BASE 187 P1033X187 WRENCH 8 X 10MM OPEN-ENDS
139 P1033X139 CHAIN 188 P1033X188 WRENCH 12 X 14MM OPEN-ENDS
140 P1033X140 IDLER BRACKET 189 P1033X189 WRENCH 17 X 19MM OPEN-ENDS
141 P1033X141 IDLER SHAFT 15 X 34MM 190 P1033X190 FLAT WRENCH 10 X 13MM OPEN-ENDS
142 P1033X142 SPROCKET 230 P1033X230 FLAT WASHER 8MM
143 P1033X143 EXT RETAINING RING 15MM 239 P1033X239 SET SCREW M10-1.5 X 12
144 P1033X144 BALL BEARING 6202ZZ 240 P1033X240 EXT RETAINING RING 12MM
145 P1033X145 INT RETAINING RING 35MM 241 P1033X241 SET SCREW M6-1 X 12
146 P1033X146 SPROCKET 242 P1033X242 BALL BEARING 6201ZZ
147 P1033X147 FLAT WASHER 10MM 243 P1033X243 FLAT WASHER 12MM
148 P1033X148 HEX NUT M10-1.25 244 P1033X244 KEY 4 X 4 X 10
149 P1033X149 DUST BOOT
