G1037Z 13" Planer/Moulder -31-
Always disconnect
power to the machine
before performing ser-
vice adjustments. Failure
to do this may result in
serious personal injury.
This section is designed to help the operator with
adjustments that were made at the factory and
that might also need to be made during the life of
the machine.
This section is provided for your convenience—it
is not a substitute for the Grizzly Service
Department. If any adjustments arise that are not
described in this manual, then feel free to call the
Grizzly Service Department at (570) 546-9663.
Similarly, if you are unsure of how to perform any
procedure in this section, the Grizzly Service
Department will be happy to guide you through
the procedures or help in any other way.
Before attempting to adjust the table, you will
need to construct the gauge block shown in
Figure 28. Do not use common 2x4 material. Use
a hard wood material like maple or oak. A pattern
for this gauge block has been provided for you on
page 45 of this manual.
Figure 28. Gauge block specifications.
Figure 29. Rotocator.
A better option is to use a Rotocator
®
similar to
the one in Figure 29. Use the Rotocator whenev-
er the instructions call for use of the gauge block
or feeler gauge. Refer to the current Grizzly cata-
log for Rotocators.
Gauge Blocks
About Service
SECTION 8: SERVICE ADJUSTMENTS
