Grizzly G1037Z User Manual

-42-
G1037Z 13" Planer/Moulder
55 P1037Z055 Cover, Right
56 P1037Z056 Shaft
57 P1037Z057 Gear Cover
58 PN35M Acorn Nut M6-1
59 P1037Z059 Bushing
60 P1037Z060 Gear
61 P1037Z061 Gear
62 PK03M Key 3 x 3 x 8
63 PW03M Flat Washer 6mm
64 P1037Z064 Pin
65 P1037Z065 Gear Box Cover
66 P1037Z066 Bushing
67 P1037Z067 Chain Sprocket Shaft
68 PK29M Key 4 x 4 x 8
69 P1037Z069 Sprocket
70 P1037Z070 Gear Box
71 P6202 Ball Bearing 6202
72 PR21M Int Retaining Ring 35mm
73 P1037Z073 Bushing
74 PW14M Flat Washer 15mm
75 P1037Z075 Gear
76 P1037Z076 Bushing
77 PR06M Ext Retaining Ring 16mm
78 PR02M Ext Retaining Ring 14mm
79 P1037Z079 Gear
80 P1037Z080 Spacer
81 P1037Z081 Gear
82 P1037Z082 Shaft
83 PK29M Key 4 x 4 x 8
84 P1037Z084 Gear
85 P1037Z085 Fence, Left
86 P1037Z086 Middle Frame
87 P1037Z087 Post
88 P1037Z088 Elevation Screw
89 PR09M Ext Retaining Ring 20mm
90 PRP37M Roll Pin 3 x 14
91 PW03M Flat Washer 6mm
92 P6004 Ball Bearing 6004
93 P1037Z093 Fixing Plate
94 P1037Z094 Shaft
95 P1037Z095 Base
96 P1037Z096 Cover, Left
97 PLW04M Lock Washer 8mm
98 PSB31M Cap Screw M8-1.25 x 25
99 PSB68M Cap Screw M6-1 x 8
100 PW03M Flat Washer 6mm
101 P1037Z101 Chain
102 P1037Z102 Sprocket
103 P1037Z103 Sprocket
104 P1037Z104 Idler Bracket
105 PW01M Flat Washer 8mm
106 PSB14M Cap Screw M8-1.25 x 20
1 PSB26M Cap Screw M6-1 x 12
2 PLW03M Lock Washer 6mm
3 P1037Z003 Dust Chute
4 P1037Z004 Chip Bracket
4-1 P1037Z004-1 Chip Guide
5 PSB86M Cap Screw M5-.8 x 10
6 PLW01M Lock Washer 5mm
7 PWN03M Wing Nut M4-.7
8 PLW02M Lock Washer 4mm
9 PW05M Flat Washer 4mm
10 PFB01M Flange Bolt M6-1 x 12
11 P1037Z011 Roller
12 P1037Z012 Bushing
13 P1037Z013 Spring
14 P1037Z014 Spacer
15 P1037Z015 Chain
16 P1037Z016 Sprocket
17 PR05M Ext Retaining Ring 15mm
18 P1037Z018 Cover
19 PSB04M Cap Screw M6-1 x 10
20 PSB13M Cap Screw M8-1.25 x 30
21 P1037Z021 Chip Guard Plate
22 PN02M Hex Nut M10-1.5
23 P1037Z023 Adjustment Shaft
24 P1037Z024 Adjustable Shaft
25 P1037Z025 Lock Nut M22
26 PS42M Phlp Hd Scr M8-1.25 x 35
27 P1037Z027 Handwheel
28 PSS14M Set Screw M8-1.25 x 12
29 P1037Z029 Long Gib
30 P1037Z030 Short Gib
31 P1037Z031 Plate
32 PSS53M Set Screw M5-.8 x 12
34 P1037Z034 Knife
35 PSB01M Cap Screw M6-1 x 16
36 PK20M Key 5 x 5 x 15
37 P1037Z037 Upper Frame
38 P6204 Ball Bearing 6204
39 P1037Z039 Cutterhead
40 PVM50 V-belt M-50 3L500
41 PSB02M Cap Screw M6-1 x 20
42 PW03M Flat Washer 6mm
44 P1037Z044 Shaft
45 P1037Z045 Fixing Plate
46 P1037Z046 Spacer
47 P1037Z047 Anti-Kickback Finger
48 P1037Z048 Chain #410 X 18
50 P1037Z050 Fence, Right
51 PS68M Phlp Hd Scr M6-1 x 10
52 P1037Z052 Pointer
53 PS07M Phlp Hd Scr M4-.7 x 8
54 PRP42M Roll Pin 3 x 20
REF PART # DESCRIPTION REF PART # DESCRIPTION
