G1037Z 13" Planer/Moulder
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G1037Z 13" PLANER/MOULDER
Design Type...................................................................................................... Floor Model
Overall Dimensions:
Table Size ..........................................................................................14
1
⁄8''W x 17
3
⁄4"D
Overall Height ......................................................................................................44
1
⁄2"
Overall Depth ..........................................................................................................23"
Overall Width ........................................................................................................23
1
⁄2"
Shipping Weight ..............................................................................................240 lbs.
Weight in Place ................................................................................................217 lbs.
Footprint ..............................................................................................21
1
⁄4"W x 22
1
⁄4D"
Box Size......................................................................................29" L x 20" W x 29" H
Capacities:
Maximum Depth of Cut ..............................................................................Planing:
1
⁄8"
Maximum Profile Depth............................................................................Moulding:
3
⁄4''
Maximum Stock Thickness ........................................................................................6"
Minimum Length Stock ............................................................................................12"
Minimum Stock Thickness ........................................................................................
3
⁄8"
Cutterhead Diameter ..............................................................................................2
5
⁄8"
Knives ..................................................................3 High Speed Steel / 13'' x
5
⁄8'' x
1
⁄8''
Cutterhead Speed ........................................................................................5000 RPM
Cuts Per Minute ................................................................................................15,000
Feed Speed ......................................................Planing: 24 FPM, Moulding: 12 FPM
Cuts Per Inch ......................................................................Planing: 52, Moulding 104
Motor:
Type ............................................................................TEFC Capacitor-Start Induction
Horsepower ........................................................................................................1
1
⁄2 HP
Phase ⁄ Cycle................................................................................Single Phase /60 Hz
Voltage ........................................................................................................110V/220V
Prewired................................................................................................................110V
RPM ......................................................................................................................3450
Amps ....................................................................................................................18 / 9
Power Transfer ................................................................................ Twin V-Belt Drive
Bearings ..............................................................Shielded & Lubricated Ball Bearings
Features:
Measurement Scale..............................................................................Inch and Metric
Feed Rollers..............................................................Fully Adjustable, Rubber Coated
..................................................................................................................4'' Dust Port
................................................................................Precision Ground Cast Iron Table
............................................................Anti-Kickback Pawls and Chip-Breaker Device
..............................................................................................4 Column Table Support
........................................................................................................2 Moulding Fences
Moulding Knives Sold Separately
Specifications, while deemed accurate, are not guaranteed.
MACHINE DATA
SHEET
