2.0 Introduction
Hybrid Power System
This is a multifunctional off grid solar inverter, integrated with a MPPT/PWM solar charge controller, a
high frequency pure sine wave inverter and a UPS function module in one machine, which is perfect for
off grid backup power and self-consumption applications. The transformerless design provides reliable
power conversion in compact size.
The whole system also need other devices to achieve complete running such as PV modules, generator, or
utility grid. Please consult with your system integrator for other possible system architectures depending on
your requirements. The WiFi / GPRS module is a plug-and-play monitoring device to be installed on the
inverter. With this device, users can monitor the status of the PV system from the mobile phone or from the
website anytime anywhere.
2.1 Features
Rated power 2KW to 5KW, power factor 1
Built-in MPPT solar charge controller
High frequency inverter with small size and light weight
Pure sine wave AC output
Overload, short circuit and deep discharge protection
Configurable AC/ solar input priority via LCD setting
Compatible to mains voltage or generator power
With CAN/RS485 for BMS communication
WIFI/ GPRS remote monitoring (optional)
Parallel operation available for 4KW/5KW (optional)
