12. Technical data
12.1 Operating conditions
12.1.1 Maximum total head
Pump type Max. head [m]
CMBE 1-44 44
CMBE 3-62 62
CMBE 3-93 93
CMBE 5-62 62
CMBE 10-54 54
12.1.2 Pressure
[bar] [MPa]
Min. inlet pressure (relative)
without pressure switch
-0.1 -0.01
Min. inlet pressure with
pressure switch
1 0.1
Max. outlet pressure 10 1
Max. operating pressure 10 1
12.1.3 Ambient temperature during storage and
transportation
-30 to +60 °C.
12.1.4
Ambient temperature during operation
-20 to +50 °C.
The motor can operate with the rated power output
(P2) at 50 °C, but continuous operation at higher
temperatures will reduce the expected product life. If
the motor is to operate at ambient temperatures
between 50 and 60 °C, an oversized motor must be
selected. Contact Grundfos for further information.
Related information
4.3 Installation altitude
12.1.5
Liquid temperature
0-60 °C.
Heat protection:
> 80 °C: The pump will stop.
< 50 °C: The pump will start automatically.
12.1.6
Sound pressure level
≤ 55 dB(A).
12.1.7
Start/stop frequency
Max. 100/h.
12.2
Supply voltage
1 × 220-240 V -10 % / +10 %, 50/60 Hz -2 % / +2 %,
PE.
12.3 Overload protection
The overload protection of the E-motor has the same
characteristic as an ordinary motor-protective circuit
breaker. As an example, the E-motor can stand an
overload of 110 % of rated current for 1 minute.
12.4 Cable requirements
DANGER
Electric shock
Death or serious personal injury
‐ Comply with local regulations as to
cable cross-sections.
‐ Use the recommended fuse size.
1 × 200-230 V
Power [kW]
Cross-section
[mm
2
]
[AWG]
0.25 - 2.2 1.5 - 2.5 16-12
Conductor types
Stranded or solid copper conductors.
Conductor temperature ratings
Temperature rating for conductor insulation: 60 °C
(140 °F).
Temperature rating for outer cable sheath: 75 °C (167
°F).
