Grundfos DDA 7.5-16 User Manual

English (GB)
28
6.6 SlowMode
When the "SlowMode" function is enabled, the
pump slows down the suction stroke. The function is
enabled in the "Setup > SlowMode" menu and is
used to prevent cavitation in the following cases:
• for dosing media with a high viscosity
• for degassing dosing media
• for long suction lines
• for large suction lift.
In the "Setup > SlowMode" menu, the speed of the
suction stroke can be reduced to 50 % or 25 %.
Fig. 32 SlowMode menu
Caution
Enabling the ' SlowMode ' function
reduces the maximum dosing flow of
the pump to the set percentage value!
TM04 1153 1110
Off
SlowMode (50% max.)
SlowMode (25% max.)
❑
❑
SlowMode

Grundfos DDA 7.5-16 Specifications

General

Max Flow Rate	7.5 l/h
Max Pressure	16 bar
Protection Class	IP65
Operating Temperature	0°C to +45°C
Analogue Control	4-20 mA
Pulse Control	Yes
Level Control	Yes
Power Supply	100-240 V, 50/60 Hz
Material	Stainless Steel
