2.6 Type key
The type key is used to identify the precise pump and is not used for configuration purposes.
* including: 2 pump connections, foot valve, injection unit, 6 m PE discharge hose, 2 m PVC suction hose,
2 m PVC deaeration hose (4/6 mm)
Code Example DDA 7.5- 16 AR- PP/ V/ C- F- 3 1 U2U2 F G
Pump type
Max. flow [l/h]
Max. pressure [bar]
AR
FC
FCM
Control variant
Standard
AR with FlowControl
FC with integrated flow measurement
PP
PVC
PV
SS
Dosing head material
Polypropylene
PVC (polyvinyl chloride, only up to 10 bar)
PVDF (polyvinylidene fluoride)
Stainless steel DIN 1.4401
E
V
T
Gasket material
EPDM
FKM
PTFE
C
SS
Valve ball material
Ceramic
Stainless steel DIN 1.4401
F
Control cube position
Front-mounted (can be changed to the right or left)
3
Voltage
1 x 100-240 V, 50/60 Hz
1
2
Valve type
Standard
Spring-loaded (HV version)
U2U2
U7U7
AA
VV
XX
I001
I002
I003
I004
Suction/discharge side connection
Hose, 4/6 mm, 6/9 mm, 6/12 mm, 9/12 mm
Hose 0.17" x 1/4"; 1/4" x 3/8"; 3/8" x 1/2"
Threaded Rp 1/4", female (stainless steel)
Threaded 1/4" NPT, female (stainless steel)
No connection
Installation set*
Hose, 4/6 mm (up to 7.5 l/h, 13 bar)
Hose, 9/12 mm (up to 60 l/h, 9 bar)
Hose, 0.17" x 1/4" (up to 7.5 l/h, 13 bar)
Hose, 3/8" x 1/2" (up to 60 l/h, 10 bar)
F
B
G
I
E
J
L
Mains plug
EU
USA, Canada
UK
Australia, New Zealand, Taiwan
Switzerland
Japan
Argentina
G
Design
Grundfos
