Grundfos MAGNA1 C Series User Manual

Appendix
39
MAGNA1 D
80-100 F
360 218 102 102 204 0 84 538 244 294 130 260 97 318 415 80 128 150/160 200 19 12
MAGNA1 D
80-120 F
360 218 102 102 204 0 84 538 244 294 130 260 97 318 415 80 128 150/160 200 19 12
MAGNA1 D
100-40 F
450 243 147 147 204 0 84 551 252 299 135 270 103 330 434 100 160 170 220 19 12
MAGNA1 D
100-60 F
450 243 147 147 204 0 84 551 252 299 135 270 103 330 434 100 160 170 220 19 12
MAGNA1 D
100-80 F
450 243 147 147 204 0 84 551 252 299 135 270 103 330 434 100 160 170 220 19 12
MAGNA1 D
100-100 F
450 243 147 147 204 0 84 551 252 299 135 270 103 330 434 100 160 170 220 19 12
MAGNA1 D
100-120 F
450 243 147 147 204 0 84 551 252 299 135 270 103 330 434 100 160 170 220 19 12
Pump type
Dimensions [mm]
L1 L2 L3 L4 L5 L7 B1 B3 B4 B5 B6 B7 H1 H2 H3 D1 D2 D3 D4 D5 M
M3: Rp 1/4 for a vent valve is available on all twin-
head pumps.

Grundfos MAGNA1 C Series Specifications

General

Head	Up to 12 m
Maximum Operating Pressure	10 bar
Power Supply	1 x 230 V, 3 x 400 V
Insulation Class	F
Type	Circulator Pump
Pump Housing	Cast Iron
Approvals	CE, EAC
Connection Type	Flanged or threaded
Material	Cast Iron
Weight	Varies depending on model
