Grundfos PHT A N - Page 16

www.grundfos.co.uk
GRUNDFOS INSTRUCTIONS
15
Status: FAULT
Sensor
System 1 Pressure Bar
23/08/2017
14.25
Status: SERVICE
System 1 Pressure 1.5 Bar
23/08/2017
14.25
Status: FAULT - SERVICE
Sensor
System 1 Pressure Bar
23/08/2017
14.25
Settings Summary
High Alarm 1.5 Bar
Set Press 1.5 Bar
Diff Press 0.2 Bar
Low Alarm 0.7 Bar
Common Diff ON
If a pressure sensor fault has been
registered, then no pressure reading will
be shown:
If the unit requires servicing, then the
Status will show SERVICE:
If a fault is present and a service is
required, then the Status will show
FAULT - SERVICE:
To check the main settings quickly all in
one place press the UP key.
With the PHT A T unit there are two
screens of settings available.
NOTE
