PNEG-2343 U-Trough Free Flow Unloading System 43
5. Power Requirements
Power requirements are dependent on the grain type, condition and moisture level. Power requirements
are suggestions and may vary in specific circumstances. Steps can be taken to reduce the power needed
to operate the unloader or sweep if the power available to the site is limited. Operating the unloader at a
slower speed and reducing the flow of grain into the unloader will reduce power requirements.
Electric Drive
All values in horsepower, (1 HP = 0.746 Kw).
Electric drive motor pulley is not provided.
For 1750 RPM motors a 3-1/2" - 3-3/4" diameter pulley is required;
For 1460 RPM motors a 4-1/4" - 4-1/2" diameter pulley is required.
U-Trough Unloader with Sweep - Horizontal Powerhead
U-Trough Unloader with Sweep - 25° Incline Elbow and Horizontal Powerhead
Bin
Diameter
6" Sweep 7-1/4" Sweep 8-1/4" Sweep 9" Sweep
12.4" Flight
Pulley
18.4" Flight
Pulley
12.4" Flight
Pulley
18.4" Flight
Pulley
12.4" Flight
Pulley
18.4" Flight
Pulley
12.4" Flight
Pulley
18.4" Flight
Pulley
18' 5 3 5 3 5 3 7.5 5
19'5555557.55
21' 5 5 5 5 5 5 7.5 5
24' 7.5 5 7.5 5 7.5 5 7.5 5
27' 7.5 5 7.5 5 7.5 5 7.5 5
30' 7.5 5 7.5 5 7.5 5 10 7.5
33' 7.5 5 7.5 5 7.5 5 10 7.5
36' 10 7.5 10 7.5 10 7.5 10 7.5
42' 10 10 10 10 10 10 15 10
48'1515151515151515
54' N/A 15 N/A 15 N/A 15 N/A 20
60' N/A 20 N/A 20 N/A 20 N/A 20
66' N/A 20 N/A 20 N/A 20 N/A 25
Bin
Diameter
6" Sweep 7-1/4" Sweep 8-1/4" Sweep 9" Sweep
12.4" Flight
Pulley
18.4" Flight
Pulley
12.4" Flight
Pulley
18.4" Flight
Pulley
12.4" Flight
Pulley
18.4" Flight
Pulley
12.4" Flight
Pulley
18.4" Flight
Pulley
18' 7.5 5 7.5 5 7.5 5 7.5 5
19' 7.5 5 7.5 5 7.5 5 7.5 5
21' 7.5 5 7.5 5 7.5 5 7.5 5
24' 7.5 5 7.5 5 7.5 5 10 7.5
27' 10 7.5 10 7.5 10 10 10 7.5
30' 10 7.5 10 7.5 10 10 10 7.5
33' 10 7.5 10 7.5 10 10 15 10
36' 10 7.5 10 7.5 10 10 15 10
42' 10 10 10 10 15 10 15 10
48'1515151515152015
54' N/A 20 N/A 20 N/A 20 N/A 20
60' N/A 20 N/A 20 N/A 25 N/A 20
66' N/A 25 N/A 25 N/A 25 N/A 25
