8. Dimensions
50 PNEG-2343 U-Trough Free Flow Unloading System
Gate Dimensions
Figure 8C
Ref # Description Ref # Description
4 Center of Bin 12 I (Minimum Bin Radius)
6
Minimum clearance required between the bin wall
and outer gate for the elevator wheel.
13 J (Maximum Bin Radius)
