8. Dimensions
PNEG-2343 U-Trough Free Flow Unloading System 51
Nominal Bin
Diameter
# of Intermediate
Gates
EFG
Distance
Between Gates
Center of Bin to
1
st
Intermediate Gate
Intermediate Gate
Center to Center
Inches MM Inches MM Inches MM
18' 1 39.3 997 75.38 1915 51.75 1314
19' 1 45.3 1149 81.38 2067 57.75 1467
21' 1 57.3 1454 93.38 2372 69.75 1772
24' 1 75.3 1911 111.38 2829 87.75 2229
27' 2 40.4 1026 76.50 1943 52.88 1343
30' 2 49.4 1254 85.50 2172 61.88 1572
33' 2 58.4 1483 94.50 2400 70.88 1800
36' 2 67.4 1711 103.50 2629 79.88 2029
39' 2 76.4 1940 112.50 2858 88.88 2257
42' 3 52.8 1340 88.88 2257 65.25 1657
44' 3 56.8 1441 92.88 2359 69.25 1759
48' 3 64.8 1645 100.88 2562 77.25 1962
50' 3 68.8 1746 104.88 2664 81.25 2064
54' 3 76.8 1949 112.88 2867 89.25 2267
57' 4 58.9 1497 95.06 2415 71.44 1815
60' 4 63.4 1611 99.56 2529 75.94 1929
66' 4 72.4 1840 108.56 2757 84.94 2157
Nominal Bin
Diameter
# of Intermediate
Gates
HIJ
Center of Bin to
Outer Gate
Minimum
Bin Radius
Maximum
Bin Radius
Inches MM Inches MM Inches MM
18' 1 84 2134 93 2362 114 2896
19' 1 90 2286 99 2515 120 3048
21' 1 102 2591 111 2819 132 3353
24' 1 120 3048 129 3277 150 3810
27' 2 138 3505 147 3734 168 4267
30' 2 156 3962 165 4191 186 4724
33' 2 174 4420 183 4648 204 5182
36' 2 192 4877 201 5105 222 5639
39' 2 210 5334 219 5563 240 6096
42' 3 228 5791 237 6020 258 6553
44' 3 240 6096 249 6325 270 6858
48' 3 264 6706 273 6934 294 7468
50' 3 276 7010 285 7239 306 7772
54' 3 300 7620 309 7849 330 8382
57' 4 318 8077 327 8306 348 8839
60' 4 336 8534 345 8763 366 9296
66' 4 372 9449 381 9677 402 10211
