2.01 Pictograms
Emergency stop
Emergency lowering function
Reset emergency stop
Direction of travel (horizontal drive motor) denoted by grey arrow
2.02 Indicator lamps and audio signals
Status Indicator
lamps
Audio signals Possible GH3
Functions
Up Down Emergency lowering Horizontal drive motor Communication
O󰀨
– stand by
O󰀨
All OK Green x x x x x
No charging Yellow,
after 15 sec
3 x Beep after 60 sec x x x x x
Low battery Yellow x x x x x
Fault on
hoist
Yellow Beeps at button activation x x
Battery
critical low
Yellow Beeps at button activation
for functions that are not possible
x x x
Over load Yellow Beeps at button activation x x
Service date
exceeded
more than
60 days
Yellow Beeps at button activation x x x x x
Less than
60 sec of
training
available
with Trainer
module
Yellow Continuous short beeps for 60 sec x x x x x
